vannicholas Van Nicholas Nootau Rohloff Speedhub Black 14-spd 2024
2024 Road
Estimate price |
5,734$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Gates -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Nootau
Suspension Fork
VNT ADV Full Carbon Adventure
Drivetrain
Cassette
Rohloff/Gates belt drive, Black; anodised coating
Crank
Rohloff/Gates belt drive, Black; anodised coating
Wheels
Rims
Ryde Andra 29 Disc
Tires
Smart Sam 65-622 (29 x 2.60)
Brakes
Brakes
Rohloff/Gates belt drive
Cockpit
Stem
VNT Alloy 7050
Handlebar
VNT Alloy 2014 Flat
Headset
FSA Gravity SX Pro
Seat
Saddle
VNT Touring Leather
Seatpost
VNT Alloy 6061
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.5 mm | 1.459 mm | 1.406 mm |
| Front Center | 673 mm | 699 mm | 724 mm | 753 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 83 mm | 83 mm | 82 mm | 84 mm |
| Stack | 621 mm | 630 mm | 642 mm | 654 mm |
| Reach | 398 mm | 420 mm | 440 mm | 465 mm |
| Top Tube Length | 579 mm | 604 mm | 628 mm | 656 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 73.7 ° | 73.7 ° |
| Seat Tube Length | 444 mm | 493 mm | 543 mm | 593 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 130 mm | 140 mm | 153 mm | 165 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1130 mm | 1155 mm | 1181 mm | 1209 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 769 mm | 804 mm | 841 mm | 878 mm |
| Wheels | 29" | 29" | 29" | 29" |
