vannicholas Van Nicholas Yukon Rohloff Speedhub 14-spd belt 2024
2024 Road
Estimate price |
5,057$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Gates -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Yukon Rohloff
Drivetrain
Cassette
Rohloff/Gates belt drive, Black; anodised coating
Crank
Rohloff/Gates belt drive, Black; anodised coating
Wheels
Rims
VNT hubs Exal LX17 rims
Tires
Schwalbe Lugano II 25mm
Brakes
Brakes
VNT Long Drop Dual Pivot Brake Calipers, Rohloff/Gates belt drive
Cockpit
Stem
VNT Alloy 6061 Adjustable
Handlebar
VNT Alloy 6061 Rohloff
Headset
FSA
Seat
Saddle
VNT Touring Leather
Seatpost
VNT Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.403 mm | 1.435 mm | 1.477 mm | 1.49 mm | 1.505 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 591 mm | 593 mm | 599 mm | 600 mm | 610 mm | 621 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 67 mm | 67 mm | 63 mm | 63 mm | 63 mm |
| Stack | 528 mm | 540 mm | 554 mm | 570 mm | 584 mm | 599 mm |
| Reach | 381 mm | 385 mm | 386 mm | 386 mm | 392 mm | 398 mm |
| Top Tube Length | 525 mm | 536 mm | 546 mm | 556 mm | 571 mm | 582 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1002 mm | 1005 mm | 1011 mm | 1012 mm | 1022 mm | 1033 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 760 mm | 775 mm | 791 mm | 808 mm | 824 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
