Vitus E-Escarpe 290 VRS 2024
2024 E-bike
Estimate price |
6,502$
Weight | 24.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select
-
Groupset SLX -
Suspension Full -
Motor Shimano mid-drive -
Battery Shimano BT-EN806-A, 630Wh, Downtube Integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-Escarpe 6061-T6 Double Butted Alloy, Internal cable routing, post mount disc brake mounts, Boost hub spacing - 148mm x 12mm thru axle, Shimano STEPS compatible. Axle Specifications: 180mm Length, 14.5mm Thread Length, M12xP1.0 Thread Pitch
Suspension Fork
RockShox Lyrik Select RC 29", 150mm travel, DebonAir, Charger RC Damper, 35mm stanchions, 110mm x 15mm Maxle Stealth axle, 44mm offset
Rear Shock
RockShox Super Deluxe Select R, DebonAir, 205mm x 60mm, trunnion
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12 Speed, Shadow Plus, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
Shimano SLX M7100, 12 Speed, Rapidfire Plus
Cassette
Geardrive GM12, 12 Speed, 11-52T Range
Crank
E*Thirteen E*Spec Plus, 34T Narrow Wide Chainring, 165mm Crank Length, 53mm Chain Line
Bottom Bracket
N/A, N/A
Chain
KMC X12, 12 Speed, 116 Links
Wheels
Front Hub
Nukeproof Neutron V2, 32H, 6 Bolt Disc Fitment, 110mm x 15mm
Rear Hub
Nukeproof Neutron V2, 32H, 6 Bolt Disc Fitment, HG Freehub, 148mm x 12mm
Rims
Front: Nukeproof Neutron V2, 29", 32H, Presta Valve, Tubeless Ready Rim Tape Installed, Rear: Nukeproof Neutron V2, 27.5", 32H, Presta Valve, Tubeless Ready Rim Tape Installed
Tires
Front: Maxxis Assegai, 29" x 2.5" WT, 3C MaxxGrip compound, EXO+ casing, Rear: Maxxis Minion DHR II, 29" x 2.4" WT, 3C MaxxTerra compound, EXO+ casing
Brakes
Brakes
SRAM DB8, Post Mount, Four Piston Caliper
Cockpit
Stem
Nukeproof Neutron AM, 6061 Alloy, 45mm length, 31.8mm Handlebar Clamp Diameter, 0° Rise
Handlebar
Nukeproof Horizon V2 Riser, 7075 Alloy, 9° Back Sweep, 31.8mm Clamp Diameter, S & M: 780mm Wide, 12mm Rise, L & XL: 800mm Wide, 25mm Rise
Grips
Vitus Lock On, N/A
Headset
Nukeproof, ZS56/28.6 upper & ZS66/46 lower to suit 1-1/8" upper tapered to 1.8" lower headtube
Seat
Saddle
Nukeproof Trail Saddle, Black, Steel Rails
Seatpost
Brand-X Ascend Dropper, Remote lever, 31.6mm Diameter, S: 125mm drop, M: 150mm drop, L & XL: 170mm drop
Motor & Battery
Motor
Shimano BT-EN806-A, 630Wh, Downtube Integrated
Battery
Shimano BT-EN806-A, 630Wh, Downtube Integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.412 mm | 1.388 mm | 1.328 mm | 1.234 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 745 mm | 763 mm | 795 mm | 843 mm |
| Rake | 33 mm | 32 mm | 33 mm | 33 mm |
| Trail | 138 mm | 139 mm | 138 mm | 138 mm |
| Stack | 617 mm | 626 mm | 635 mm | 644 mm |
| Reach | 437 mm | 451 mm | 478 mm | 522 mm |
| Top Tube Length | 578 mm | 595 mm | 619 mm | 660 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 480 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1193 mm | 1211 mm | 1243 mm | 1291 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 840 mm | 842 mm | 849 mm | 863 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 200 cm |
