Vitus E-Mach 3 Electric Hybrid 2023
2023 E-bike
Estimate price |
3,115$
Weight | 17.2 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT Advent -
Suspension Rigid -
Motor Shimano mid-drive -
Battery Shimano STEPS E8010 504Wh, BT-E8010, 504Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
162cm - 169cm
SM
166cm - 174cm
MD
171cm - 177cm
LG
174cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-Mach 3 Aluminium, 6061-T6 Double Butted Aluminium, Shimano STEPS 6100 Motor Mount, Internal Cable Routing, Flat Mount, Mud Guard Mounts, Rack Mounts
Suspension Fork
Mach 3 Carbon, UD Carbon, Tapered Steerer, 100 x 12mm Axle, Flat Mount, Mud Guard Mounts
Rear Shock
N/A, N/A
Drivetrain
Rear Derailleur
Microshift Advent, 9 Speed
Front Derailleur
N/A, N/A
Shift Levers
Microshift Advent, 9 Speed, Trigger Shifter
Cassette
Microshift Advent H Series, 11-42T, 9 Speed
Crank
Prowheel, 42T, 170mm Crank Arm
Bottom Bracket
N/A, N/A
Chain
KMC e9 Sport, 9 Speed, E-Bike Specific
Wheels
Front Hub
Vitus KT, MSCF, 6-Bolt Disc Brake, 100 x 12mm
Rear Hub
Vitus KT, SNCR, 6-Bolt Disc Brake, 142 x 12mm
Rims
Vitus Shining, DB-21, 700c, 32 Hole
Tires
Front: Vee Tire Co. G-Sport, 700 x 35c, Rear: Vee Tire Co. G-Sport, 700 x 35c
Brakes
Brakes
C-Star BH-RS925, Hydraulic Disc, Flat Mount
Cockpit
Stem
Vitus Integrated Flat Bar & Stem, 6061 Aluminium, Bar Bore 31.8mm, +/- 15 Degree,
Handlebar
Vitus Integrated Flat Bar & Stem, 6061 Aluminium, 4 Degree Rise, 9 Degree Sweep, XXS: 640mm, XS: 640mm, S: 640mm, M: 680mm, L: 680mm, XL: 680mm
Grips
Vitus Ergo Grips, Anti Slip, Ergonomic Shape, Integrated Lock Ring
Headset
ACROS Aix-Low R3, Sealed Bearings, OD46, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
Vitus, Steel Rail
Seatpost
Vitus 6061 Aluminium, 27.2mm x 300mm
Motor & Battery
Motor
Shimano STEPS E8010 504Wh, BT-E8010, 504Wh
Battery
Shimano STEPS E8010 504Wh, BT-E8010, 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.39 mm | 1.4 mm | 1.4 mm |
| Front Center | 611.6 mm | 617.4 mm | 627.5 mm | 638.7 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 77 mm | 73 mm | 70 mm | 68 mm |
| Stack | 527 mm | 543 mm | 558 mm | 574 mm |
| Reach | 385 mm | 391 mm | 400 mm | 409 mm |
| Top Tube Length | 546 mm | 559.5 mm | 573 mm | 589.2 mm |
| Seat Tube Angle | 73.25 ° | 73 ° | 73 ° | 72.8 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 520 mm |
| Head Tube Angle | 70.4 ° | 71 ° | 71.4 ° | 71.7 ° |
| Head Tube Length | 122 mm | 136 mm | 150 mm | 166 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1033 mm | 1039 mm | 1049 mm | 1061 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 166 cm | 171 cm | 174 cm |
| Rider Max Height | 169 cm | 174 cm | 177 cm | 182 cm |
About this model
E-Mach 3 Electric Hybrid is part of the Vitus E E Mach model. 1 e-bike variation carries this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 2796$. In conclusion, this e-bike price is 12.74% higher than the price of the average Hybrid e-bike.
Average weight for Hybrid e-bikes
On a deeper look, we notice that the average weight of a Hybrid e-bike is 23.79 kg (52.45 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
much lighter than average, E-Mach 3 Electric Hybrid has a weight of 17.2 kg (37.92 lbs). In other words, this model is 38.31% lighter than the average Hybrid e-bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
E-Mach 3 Electric Hybrid components
Fork material
E-Mach 3 Electric Hybrid has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The E-Mach 3 Electric Hybrid 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Vitus E-Mach 3 Electric Hybrid has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 162 cm – 182 cm (5.31 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
