Vitus Rapide FS CRS 2024
2024 Mountain
Estimate price |
3,928$
Weight | 11.7 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rapide FS UD Carbon Full Suspension Frame, Post disc brake mounts, BSA threaded BB, Boost hub spacing – 148mm x 12mm thru axle. Axle Specifications: 181mm Length, 20mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
RockShox SID SL Select RL 29”, 100mm travel, Remote Lockout, DebonAir, Charger RL Damper, 32mm stanchions, tapered alloy steerer, Boost hub spacing – 110mm x 15mm Maxle Stealth axle, 44mm Offset
Rear Shock
RockShox SIDLuxe Select+, Remote Lockout, trunnion mount, DebonAir, 165mm x 40mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
SRAM NX Eagle, 12 Speed, Trigger Shifter
Cassette
SRAM PG-1230 Eagle, 12 Speed, 11-50T Range
Crank
SRAM Stylo 7K Eagle, 12 Speed, 30T Narrow Wide Chainring, Crank Length: S: 170mm, M, L & XL: 175mm
Bottom Bracket
SRAM DUB, BSA Threaded BB, 73mm Shell
Chain
SRAM NX Eagle, 12 Speed, 116 Links
Wheels
Front Hub
DT Swiss X 1900 Spline, 6 Bolt Disc Fitment, 110mm x 1mm
Rear Hub
DT Swiss X 1900 Spline, 6 Bolt Disc Fitment, HG Freehub, 148mm x 12mm
Rims
Front: DT Swiss X 1900 Spline, 29", 25mm Inner Rim Width, Presta Valve, Tubeless Ready Rim Tape Installed, Rear: DT Swiss X 1900 Spline, 29", 25mm Inner Rim Width, Presta Valve, Tubeless Ready Rim Tape Installed
Tires
Front: Maxxis Rekon Race, 29" x 2.25", EXO casing, Rear: Maxxis Rekon Race, 29" x 2.25", EXO casing
Brakes
Brakes
SRAM DB8, Post Mount, Four Piston Caliper
Cockpit
Stem
Vitus 6061 Alloy, Reach - S & M: 60mm, L:70mm, XL: 80mm, 31.8mm Handlebar Clamp Diameter, -7° Rise
Handlebar
Vitus 6061 Alloy, 5mm rise, 9° back sweep, S: 720mm wide, M/ L/XL: 740mm wide
Grips
Vitus Lock On, N/A
Headset
Acros AiX-322 R3, IS41.8/28.6 upper & IS52/40 lower to suit 1-1/8" upper tapered to 1.5" lower headtube
Seat
Saddle
WTB SL8 Comp, 142mm wide, Black, CrMo Rails
Seatpost
Vitus 6061 Alloy, 31.6mm Diameter x 400mm Long
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.246 mm | 1.212 mm | 1.2 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm |
| Front Center | 725 mm | 759 mm | 790 mm | 817 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 583 mm | 592 mm | 606 mm | 624 mm |
| Reach | 445 mm | 475 mm | 500 mm | 520 mm |
| Top Tube Length | 578 mm | 612 mm | 640 mm | 664 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 410 mm | 440 mm | 490 mm | 540 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1159 mm | 1193 mm | 1224 mm | 1251 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 200 cm |
