Vitus Sommet 290 CRX 2024
2024 Mountain
Estimate price |
6,231$
Weight | 15.7 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 162mm -
Fork Fox Factory Float 38
-
Groupset GX Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sommet T700 carbon front triangle, 6061-T6 alloy rear, Internal cable routing, post disc brake mounts, BSA threaded BB, Boost hub spacing – 148mm x 12mm thru axle. Axle Specifications: 180mm Length, 13mm Thread Length, M12xP1.0 Thread Pitch
Suspension Fork
Fox 38 Float EVOL Factory Series 29", 170mm travel, Kashima coating, Grip2 damper, 38mm stanchions, 110mm x 15mm bolt through axle, 44mm offset
Rear Shock
Fox Float X2 Factory Series, Kashima coating, 2 position lever, 205mm x 62.5mm, trunnion
Drivetrain
Rear Derailleur
SRAM GX Eagle T-Type AXS, 12 Speed, Wireless Electronic, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
SRAM AXS Pod Controller, 12 Speed, Wireless Electronic, MMX Clamp
Cassette
SRAM GX Eagle T-Type, 12 Speed, 10-52T Range
Crank
SRAM GX Eagle T-Type, 12 Speed, 30T Narrow Wide Chainring, 170mm Crank Length
Bottom Bracket
SRAM DUB, BSA Threaded BB, 73mm Shell
Chain
SRAM GX T-Type, 12 Speed, 118 Links
Wheels
Front Hub
Nukeproof Horizon V2, 32H, 6 Bolt Disc Fitment, 110mm x 15mm
Rear Hub
Nukeproof Horizon V2, 32H, 6 Bolt Disc Fitment, XD Freehub, 148mm x 12mm
Rims
Front: Nukeproof Horizon V2, 29", 32H, Presta Valve, Tubeless Ready Rim Tape Installed, Rear: Nukeproof Horizon V2, 29", 32H, Presta Valve, Tubeless Ready Rim Tape Installed
Tires
Front: Maxxis Assegai, 29" x 2.50" WT, 3C MaxxGrip compound, EXO+ casing, Rear: Maxxis Minion DHR II, 29" x 2.4", 3C MaxxTerra compound, DD casing
Brakes
Brakes
Hayes Dominion A4, Post Mount, Four Piston Caliper
Cockpit
Stem
Nukeproof Horizon, 6061 Alloy, 50mm length, 31.8mm Handlebar Clamp Diameter, 5° Rise
Handlebar
Nukeproof Horizon V2 Riser, 7075 Alloy, 25mm Rise, 9° Back Sweep, 31.8mm Clamp Diameter, S & M: 760mm Wide, L & XL: 780mm Wide
Grips
Vitus Lock On, N/A
Headset
Nukeproof, ZS44/28.6 upper & ZS56/40 lower to suit 1-1/8" upper tapered to 1.5" lower headtube
Seat
Saddle
Nukeproof Horizon Enduro Saddle, Black, Ti Alloy Rails
Seatpost
Brand-X Ascend Dropper, Remote lever, 31.6mm Diameter, S: 125mm drop, M: 150mm drop, L & XL: 170mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.419 mm | 1.354 mm | 1.256 mm |
| Front Center | 756 mm | 786 mm | 818 mm | 867 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 621 mm | 630 mm | 639 mm | 648 mm |
| Reach | 418 mm | 444 mm | 472 mm | 516 mm |
| Top Tube Length | 568 mm | 597 mm | 621 mm | 662 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 77 ° | 77.5 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1195 mm | 1225 mm | 1257 mm | 1306 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 200 cm |
