Vitus Substance Carbon HT Rival 2024
2024 Road
Estimate price |
3,344$
Weight | 10.1 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 30mm -
Fork RockShox Rudy XPLR
-
Groupset Rival -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 164cm
SM
161cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Substance Carbon, UD Carbon, Internal Cable Routing, Flat Mount, 1x Dropper Post Compatible, Mudguard Mounts, Rack Mounts, 12mm x 142mm Hub Spacing, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
RockShox Rudy XPLR, 30mm Travel, Tapered Steerer, 100 x 12mm, Flat Mount
Drivetrain
Rear Derailleur
SRAM Rival, 11 Speed, Long Cage
Front Derailleur
undefined, N/A
Shift Levers
SRAM Rival, 11 Speed
Cassette
SRAM PG 1130, 11 Speed, 11-42T
Crank
SRAM Rival X-Sync, 40T, 11 Speed, XS:170mm S:170mm M:172.5mm L:172.5mm XL:175mm
Bottom Bracket
SRAM GXP, BSA Threaded, 68mm, English
Chain
KMC X11, 11 Speed
Wheels
Front Hub
Prime SR2D, 12x100mm, Centre Lock
Rear Hub
Prime SR2D, 142x12mm, Centre Lock, HG Freehub, 36T Ratchet System
Rims
Front: Prime Orra V2 Alloy, 650b, Tubeless Ready, Rear: Prime Orra V2 Alloy, 650b, Tubeless Ready
Tires
Front: Maxxis Rambler, 650b x 47, Tubeless Ready, EXO Casing, Tan Wall, Rear: Maxxis Rambler, 650b x 47, Tubeless Ready, EXO Casing, Tan Wall
Brakes
Brakes
SRAM Rival, Hydraulic Disc, Flat Mount
Cockpit
Stem
FSA Omega 6061 Aluminium, 3D Forged, Bar Bore: 31.8mm, +/- 6 degrees, XS:80mm S:90mm M:90mm L:100mm XL:110mm
Handlebar
FSA Adventure Compact Handlebars, 6061 Aluminium, 80mm Reach, 125mm Drop, 12 Degree Flare, XS:400mm S:420mm M:420mm L:440mm XL:440mm
Grips
Vitus Super Grip, Anti Slip, Shockproof
Headset
ACROS Aix-Low R3, Sealed Bearings, OD48, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
Vitus, Ti Rail
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.466 mm | 1.507 mm | 1.531 mm | 1.554 mm | 1.59 mm |
| Front Center | 589.1 mm | 595.3 mm | 595.4 mm | 605.7 mm | 615.2 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 59 mm | 61 mm | 53 mm | 50 mm | 43 mm |
| Stack | 536.6 mm | 557.4 mm | 568 mm | 589.8 mm | 608.9 mm |
| Reach | 366 mm | 369.8 mm | 371 mm | 379.6 mm | 382.9 mm |
| Top Tube Length | 525 mm | 535 mm | 545 mm | 560 mm | 575 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1020 mm | 1021 mm | 1025 mm | 1036 mm | 1052 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 154 cm | 161 cm | 169 cm | 177 cm | 184 cm |
| Rider Max Height | 164 cm | 172 cm | 180 cm | 187 cm | 193 cm |
