Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Suntour 29, steerer:28.6X255MM, 120mm travel
Drivetrain
Rear Derailleur
Microshift Advent RD-M6195M, 40-46T
Cassette
Microshift, 9 speed, 11-46t
Crank
9 speed 170mm, 32T steel (S/M/L - 170mm, XL - 175mm)
Chain
KMC X9, 9 speed, 1/2'X11/128', 12000 links
Wheels
Front Hub
Alloy, 15mm bolt-through axle
Rear Hub
Alloy, 10mm bolt-through axle
Rims
29" Alloy, black, 32H
Tires
Maxxis Ardent, 27 TPI
Brakes
Brakes
Front: Clarks clout disc, 180mm rotor, Rear: Clarks clout disc, 180mm rotor
Cockpit
Handlebar
Voodoo Alloy, 31.8mm clamp
Grips
Black, lock-on
Headset
1 1/8", Tapered 44mm upper and 56mm lower
Seat
Seatpost
Voodoo Alloy 31.6mm, (S-350mm, M/L/XL - 400mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.4 mm | 1.37 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Stack | 633 mm | 637 mm | 637 mm | 646 mm |
| Reach | 416 mm | 434 mm | 454 mm | 472 mm |
| Top Tube Length | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 410 mm | 460 mm | 480 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
BRAAG is part of the Voodoo Braag model. Voodoo released 4 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Voodoo released this model in 2022, its price was 748$. Comparing the average cost of a Trail bike to this one, you will see that BRAAG price is 269.25% smaller.
Overview of components
Fork
The fork installed on this bike is the Suntour model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The BRAAG 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Voodoo BRAAG is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
BRAAG comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
