Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Suspension Rigid -
Motor 250W 80Nm mid-drive -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 182cm
XL
177cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Vvolt Alloy w/Removable Downtube Battery, fender, rack and 1x bottle cage mounts
Suspension Fork
Vvolt Alloy 15mm Thru-Axle w/ fender and accessory mounts
Drivetrain
Shift Levers
Enviolo Twist Shifter w/ Indicator
Cassette
Gates CDX, 22t
Crank
Alloy, Black; Gates CDX, 50t
Pedals
Plastic platform w/reflectors
Wheels
Front Hub
Sealed Bearing, 15x100mm Thru-Axle Disc, 28h
Rear Hub
Enviolo TR bolt-on, 32h
Rims
Lightweight Alloy 700c Disc Specific, 28h front 32h rear Black
Spokes
14g front, 12g rear Black Steel
Tires
700x40, hybrid tread for road and gravel
Brakes
Brakes
CStar Radius Hydraulic, 160mm rotors
Cockpit
Stem
Alloy, 31.8 clamp, 80mm length x 10º rise
Handlebar
Alloy, 31.8 clamp, 520mm width, 15mm rise x 10º sweep
Grips
Dual-Density Locking
Seat
Saddle
Hybrid Gel Comfort Saddle
Seatpost
27.2 x 350mm
Motor & Battery
Motor
MPF6C, 250W nominal power, 500w Max, 80nm max torque
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | XL |
|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.45 mm |
| Front Center | 671 mm | 691 mm |
| Rake | 46 mm | 45 mm |
| Trail | 78 mm | 79 mm |
| Stack | 603 mm | 636 mm |
| Reach | 431 mm | 440 mm |
| Top Tube Length | 609 mm | 628 mm |
| Seat Tube Angle | 73.4 ° | 73.4 ° |
| Seat Tube Length | 440 mm | 480 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 215 mm |
| Chainstay Length | 476 mm | 476 mm |
| Wheelbase | 1139 mm | 1159 mm |
| Bottom Bracket Drop | 65 mm | 65 mm |
| Standover Height | 741 mm | 781 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 165 cm | 177 cm |
| Rider Max Height | 182 cm | 195 cm |
Model Overview
Proxima belongs to the Vvolt E Proxima model. 1 e-bike variation carries this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Vvolt Proxima price was 2699$. Doing a quick comparison, we notice that Proxima price is 8.83% more expensive than the average cost of a Hybrid e-bike.
Proxima components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When it comes to wheels, the Proxima e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Proxima comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 2 sizes available for this model. Rider height can be anywhere between 165 cm – 195 cm (5.41 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
