Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE FAT AL 26 (5x190mm)
Suspension Fork
WHITE FAT AL 26 (5x150mm)
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000-GS
Shift Levers
Shimano Deore SL-M6000-R
Cassette
SunRace CSMS2, 11-42T
Crank
FSA Comet Modular 1x DM MegaExo Fatbike, 28T (175mm M-XL)
Chain
KMC X10 NPBK
Wheels
Front Hub
KT-M9DF
Rear Hub
KT-SL8R
Rims
WHITE FD90 32h
Tires
Schwalbe Jumbo Jim Performance 26x4.8 ADDIX
Brakes
Brakes
Tektro HD-M275 (180/180)
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Pro 760mm
Grips
WHITE ControlGrip Comp lock-on
Headset
FSA NO.42/ACB
Seat
Saddle
Selle Italia X1
Seatpost
WHITE ControlPost Pro 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
