Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Tektro MD Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE AX AL R
Suspension Fork
WHITE AX ST
Drivetrain
Rear Derailleur
Shimano RD-M310-L
Shift Levers
Shimano SL-M315-8R
Cassette
Shimano CS-HG31-8, 11-34T
Crank
Prowheel, 38T
Chain
KMC Z8.1 GYGY
Wheels
Front Hub
Joytech D761DSE
Rear Hub
Joytech D762DSE
Rims
WHITE TD18 32h
Tires
Urban 700x45C (47-622)
Brakes
Brakes
Tektro MD-280
Cockpit
Stem
WHITE ControlStem Comp 31.8mm
Handlebar
WHITE ControlBar Comp 740mm
Grips
WHITE ControlGrip Ergo lock-on
Headset
1-1/8" Zero Stack Threadless
Seat
Saddle
Sport Comfort
Seatpost
WHITE ControlPost Comp 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
