Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Motor hub-drive -
Drivetrain Internally Geared Hub -
Brakes Tektro Coaster
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Easy entry aluminium
Suspension Fork
Rigid steel
Drivetrain
Shift Levers
Shimano Nexus 3 Revoshift SL-3S41E
Cassette
Shimano SM-GEAR18, 18T
Crank
Prowheel, 38T (170mm)
Chain
KMC S1 Wide RB
Wheels
Front Hub
Shengyi brushless front motor
Rear Hub
Shimano Nexus 3 SG-3C41
Rims
Alloy double wall 36h
Tires
CST Xpedium One 40-622 (700x38C)
Brakes
Brakes
Front: Tektro V-brake, Rear: Coaster brake
Cockpit
Stem
Alloy adjustable 25.4mm
Handlebar
Alloy 620mm
Grips
Velo comfort 125/92mm
Headset
1-1/8" Zero Stack Threaded
Seat
Saddle
Velo comfort
Seatpost
Alloy 27.2mm
Motor & Battery
Motor
Shengyi brushless front motor
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
