Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE E-XC AL 29
Suspension Fork
SR Suntour XCM HLO 100mm
Drivetrain
Rear Derailleur
Shimano Alivio RD-M3100-SGS
Front Derailleur
n/a
Shift Levers
Shimano Alivio SL-M3100-R
Cassette
Shimano CS-HG200-9, 11-36T
Crank
Shimano FC-E5010, 38T
Chain
KMC e9 Silver/Black
Pedals
WHITE MTB PP 9/16"
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
WHITE MD23 32h
Tires
WTB Ranger Comp 29x2.25
Brakes
Brakes
Shimano BL-MT201/BR-MT200
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Lite 760mm
Grips
WHITE ControlGrip Ergo lock-on
Headset
FSA NO.57E-1
Seat
Saddle
WHITE ControlSeat Comp
Seatpost
WHITE ControlPost Comp 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
