Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Shimano GRX 400 Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE GX CF (12x142mm)
Suspension Fork
WHITE GX CF (12x100mm)
Drivetrain
Rear Derailleur
Shimano GRX RD-RX812
Shift Levers
Shimano GRX ST-RX600-R
Cassette
Shimano Deore CS-M5100-11, 11-42T
Crank
Shimano GRX FC-RX600-1, 40T
Chain
KMC X11 NPBK
Wheels
Front Hub
Shimano HB-RS470
Rear Hub
Shimano FH-RS470
Tires
WTB Riddler 700x37C DNA TCS
Brakes
Brakes
Shimano GRX BL-RX400/BR-RX400
Cockpit
Stem
WHITE ControlStem Race 31.8mm
Handlebar
WHITE ControlBar Gravel Race
Grips
WHITE ControlGrip tape
Headset
FSA NO.42/48/ACB
Seat
Saddle
WTB SL8 142 Race
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.512 mm | 1.511 mm | 1.53 mm | 1.546 mm | mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | mm |
| Front Center | 601 mm | 601 mm | 611 mm | 626 mm | mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | mm |
| Trail | 70 mm | 64 mm | 61 mm | 61 mm | mm |
| Stack | 567 mm | 568 mm | 589 mm | 609 mm | mm |
| Reach | 375 mm | 376 mm | 385 mm | 394 mm | mm |
| Top Tube Length | 535 mm | 550 mm | 565 mm | 580 mm | mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm | mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | ° |
| Head Tube Length | 140 mm | 150 mm | 170 mm | 190 mm | mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | mm |
| Wheelbase | 1027 mm | 1026 mm | 1037 mm | 1052 mm | mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | mm |
| Standover Height | 786 mm | 803 mm | 823 mm | 841 mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
