Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Promax Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE GX AL
Suspension Fork
WHITE GX CF
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-GS
Front Derailleur
Shimano Claris FD-R2000-B
Shift Levers
Shimano Claris ST-R2000-L/R
Cassette
Shimano Claris CS-HG-50-8, 11-34T
Crank
Shimano Claris FC-R2000, 46/34T
Chain
KMC Z8.3 NPGY
Wheels
Front Hub
Joytech D761DSE
Rear Hub
Joytech D762DSE
Rims
WHITE RD29 32h
Tires
WTB Riddler 700x37C Comp
Brakes
Brakes
Promax Decode R
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Road Comp
Grips
WHITE ControlGrip tape
Headset
FSA NO.42/ACB
Seat
Saddle
WHITE ControlSeat Comp
Seatpost
WHITE ControlPost Comp 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.458 mm | 1.503 mm | 1.52 mm | 1.555 mm | mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | mm |
| Stack | 551 mm | 580 mm | 599 mm | 625 mm | mm |
| Reach | 378 mm | 386 mm | 394 mm | 402 mm | mm |
| Top Tube Length | 541 mm | 558 mm | 572 mm | 587 mm | mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | ° |
| Head Tube Angle | 70 ° | 71.5 ° | 71.5 ° | 72 ° | ° |
| Head Tube Length | 135 mm | 160 mm | 180 mm | 205 mm | mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
