Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 60mm -
Fork Zoom
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 26 S
Suspension Fork
Zoom Masera 386A 60mm
Drivetrain
Rear Derailleur
Shimano RD-M591-L
Shift Levers
Shimano SL-M315-8R
Cassette
Shimano CS-HG31-8, 11-34T
Crank
Alloy, 28T
Chain
KMC Z8.3 NPGY
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
WHITE MD18 32h
Tires
Kenda Small Block 8 26x1.95
Brakes
Brakes
Shimano BL-MT200/BR-MT200
Cockpit
Stem
WHITE ControlStem Comp 31.8mm
Handlebar
WHITE ControlBar Comp 620mm
Grips
WHITE ControlGrip lock-on jr
Headset
1-1/8" External Cup Threadless
Seat
Saddle
WHITE ControlSeat Pro jr
Seatpost
WHITE ControlPost Comp 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
