Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Zoom
-
Groupset Deore, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 27
Suspension Fork
Zoom Vaxa 30 HLO 100mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M592-SGS
Front Derailleur
Shimano FD-TY700-TS6
Shift Levers
Shimano SL-M315-L/8R
Cassette
SunRace CSM66, 11-34T
Crank
Shimano FC-TY501, 42/34/24T
Chain
KMC X8 NPGY
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
WHITE MD20 32h
Tires
Kenda K1153 27.5x2.10
Brakes
Brakes
Shimano BL-MT200/BR-MT200
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Lite 680mm
Grips
WHITE ControlGrip Comp lock-on
Headset
FSA NO.10
Seat
Saddle
WHITE ControlSeat Comp
Seatpost
WHITE ControlPost Comp 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.519 mm | 1.444 mm | mm | mm | mm |
| Bottom Bracket Height | 305 mm | 305 mm | mm | mm | mm |
| Stack | 585 mm | 585 mm | mm | mm | mm |
| Reach | 385 mm | 405 mm | mm | mm | mm |
| Top Tube Length | 564 mm | 584 mm | mm | mm | mm |
| Seat Tube Angle | 73 ° | 73 ° | ° | ° | ° |
| Head Tube Angle | 68.8 ° | 68.8 ° | ° | ° | ° |
| Head Tube Length | 100 mm | 100 mm | mm | mm | mm |
| Chainstay Length | 435 mm | 435 mm | mm | mm | mm |
| Bottom Bracket Drop | 50 mm | 50 mm | mm | mm | mm |
| Standover Height | 724 mm | 755 mm | mm | mm | mm |
| Front Travel | 100 mm | 100 mm | mm | mm | mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
