Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork RST CAPA
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 27 S
Suspension Fork
RST Capa 27.5" ML 80mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000-GS
Shift Levers
Shimano Deore SL-M6000-R
Cassette
SunRace CSMS2, 11-42T
Crank
Alloy, 32T Narrow Wide
Chain
KMC X10 NPBK
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
WHITE MD19 32h
Tires
Kenda Small Block 8 27.5x2.10
Brakes
Brakes
Shimano BL-MT200/BR-MT200
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Comp 660mm
Grips
WHITE ControlGrip lock-on jr
Headset
1-1/8" Zero Stack Threadless
Seat
Saddle
WHITE ControlSeat Pro jr
Seatpost
WHITE ControlPost Comp 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
