Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy Gold RL
-
Groupset X1, GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 29
Suspension Fork
Rock Shox Judy Gold RL 100mm w/ OneLoc remote
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle Trigger
Cassette
SRAM PG-1230, 11-50T
Crank
SRAM X1 1000 Eagle, 34T
Chain
SRAM NX Eagle
Wheels
Front Hub
Shimano HB-MT400-B
Rear Hub
Shimano FH-M3050
Rims
WTB ST i23 TCS 2.0 32h
Tires
Maxxis Recon Race 29x2.25 60TPI
Brakes
Brakes
Shimano BL-MT401/BR-MT400
Cockpit
Stem
WHITE ControlStem Race 31.8mm
Handlebar
WHITE ControlBar Pro 720mm
Grips
WHITE ControlGrip Pro lock-on
Headset
FSA NO.42/ACB
Seat
Saddle
WTB SL8 142 Comp
Seatpost
WHITE ControlPost Pro 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.428 mm | 1.385 mm | mm | mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | mm | mm |
| Stack | 612 mm | 621 mm | 630 mm | mm | mm |
| Reach | 415 mm | 435 mm | 455 mm | mm | mm |
| Top Tube Length | 594 mm | 616 mm | 639 mm | mm | mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | ° | ° |
| Head Tube Angle | 69.3 ° | 69.3 ° | 69.3 ° | ° | ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | mm | mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | mm | mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | mm | mm |
| Standover Height | 771 mm | 809 mm | 844 mm | mm | mm |
| Front Travel | 100 mm | 100 mm | 100 mm | mm | mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
