Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 29
Suspension Fork
Rock Shox Judy TK 100mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100-SGS
Shift Levers
Shimano Deore SL-M5100-R
Cassette
SunRace CSMS8, 11-50T
Crank
FSA Comet Modular 1x DM MegaExo Boost148, 34T
Chain
KMC X11 NPBK
Wheels
Front Hub
Shimano HB-MT200
Rear Hub
Shimano FH-MT200-B
Rims
WHITE MD20 32h
Tires
Maxxis Recon Race 29x2.25 60TPI
Brakes
Brakes
Shimano BL-MT201/BR-MT200
Cockpit
Stem
WHITE ControlStem Pro 31.8mm
Handlebar
WHITE ControlBar Lite 740mm
Grips
WHITE ControlGrip Comp lock-on
Headset
FSA NO.42/ACB
Seat
Saddle
WHITE ControlSeat Comp
Seatpost
WHITE ControlPost Comp 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
