Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Judy
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Get A Grip Seat Clamp System, Internal Cable Routing with BBX, Chainstay Post Mount Dropouts
Suspension Fork
RockShox Judy TK 27.5", 120mm Travel, Adjustable Rebound, Turn Key Lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore RD-M5020-SGS, Shadow Plus, 10 Speed
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M4010, 10 Speed
Cassette
SunRace CSMS2, ED Black, 11-46, 10 Speed
Crank
Whyte, Forged 2pcs Cranks, 32T Narrow/Wide Chainring, 170mm, 10 Speed
Bottom Bracket
BSA, Cartridge Bearings, 73mm
Chain
SunRace, 10 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Cup & Cone, Double Seal, 32 Hole
Rear Hub
Alloy, Cup & Cone, Double Seal, 32 Hole
Rims
Whyte Trail 25, Tubeless Compatible, 32 Hole
Spokes
2.0mm, PG, Black Stainless, Brass Nipples
Tires
WTB Trail Boss Comp 27.5" x 2.25" Front, WTB Ranger Comp 27.5" x 2.25" Rear
Brakes
Brakes
Tektro HD-M275, Hydraulic, 180mm Disc
Brake Levers
Tektro HD-M275
Cockpit
Stem
Whyte Alloy, S 35mm, M/L/XL 45mm Extension
Handlebar
Whyte 6061 Alloy, 25mm Rise, 31.8mm, 760mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No.10, Semi Integrated, 1 1/8" Caged Bearings
Seat
Saddle
Whyte Custom
Seatpost
Whyte 6061 Alloy, 12mm Offset, 30.9mm x S/M 350mm, L/XL 400mm, 2 Bolt Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.39 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 303.5 mm | 303.5 mm | 303.5 mm | 303.5 mm |
| Stack | 615 mm | 625 mm | 634 mm | 643 mm |
| Reach | 436 mm | 451 mm | 467 mm | 483 mm |
| Top Tube Length | 610 mm | 629 mm | 647 mm | 666 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 444 mm | 482.6 mm | 533 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1154 mm | 1174 mm | 1194 mm | 1214 mm |
| Bottom Bracket Drop | 52 mm | 52 mm | 52 mm | 52 mm |
| Standover Height | 786 mm | 808 mm | 832 mm | 870 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
605 v3 is part of the Whyte 605 model. There are 3 bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2021 for 943$. Comparing the average cost of a Trail bike to this one, you will see that 605 v3 price is 192.9% smaller.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This bike has the RockShox Judy fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Whyte 605 v3 2021, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The 605 v3 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
605 v3 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
