Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Recon Gold RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL Gold, Fast Black coating, Solo Air, adjustable compression and rebound, tapered steerer, 110x15mm Boost, Maxle Lite
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM PG-1130, 11-42 tooth, 11-speed
Crank
SRAM NX, Boost
Bottom Bracket
SRAM GXP, 73mm
Chain
SRAM PC-1110, 11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Alloy, double sealed cartridge bearing, 32 hole, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Alloy, double sealed cartridge bearing, 32 hole, 110x15mm Boost front, 148x12mm Boost rear
Rims
WTB STp i29, TCS System, tubeless ready, 32 hole
Spokes
WTB 2.0mm, black Sandvik stainless steel, brass nipples
Tires
Maxxis Forekaster TR, 60tpi, 3C (Maxx Terra) folding bead, EXO sidewall protection, 27.5" x 2.6"
Brakes
Brakes
SRAM Level, 180mm front rotor, 160mm rear rotor (200mm front and 180mm rear rotors on XL)
Brake Levers
SRAM Level
Cockpit
Stem
Whyte Gravity, 40mm length (S/M), 50mm length (L/XL)
Handlebar
Whyte Custom alloy, low rise, 760mm width (30mm rise and 780mm width on XL)
Grips
Whyte lock-on V
Headset
FSA No. 57B Orbit ZS, caged bearings
Seat
Saddle
Whyte Custom, triple panel design
Seatpost
Whyte, 6061 alloy, 20mm offset, 350mm length (S/M), 400mm length (L/XL), 2-bolt clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 297.5 mm | 297.5 mm | 297.5 mm | 297.5 mm |
| Stack | 629.6 mm | 638.5 mm | 647.6 mm | 656.7 mm |
| Reach | 435.6 mm | 451.5 mm | 467.2 mm | 482.9 mm |
| Top Tube Length | 627.4 mm | 645.4 mm | 664.4 mm | 681.8 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 484.6 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1167 mm | 1187 mm | 1207 mm | 1233 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 794 mm | 799 mm | 825 mm | 831 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
901 completes the Whyte 901 model. Whyte launched 10 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
slightly lighter than average, 901 has a weight of 12.8 kg (28.22 lbs). In other words, this model is 1.41% lighter than the average Trail bike.
901 components
Fork
This bike has the RockShox Recon Gold RL fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the 901 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
