Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Float Performance 34, GRIP 3-position, black coating, 37mm offset, 15mm x 110mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, MMX, 12-speed
Cassette
SRAM XG-1275 Eagle, 10-50 tooth, 12-speed
Crank
SRAM GX Eagle, X-sync 2, DUB, 170mm
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM Eagle, 12-speed
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Front: Alloy, double sealed cartridge bearings, 15mm x 110mm Boost, Rear: Hope Pro 4, sealed stainless steel cartridge bearings, 12mm x 148mm Boost
Rear Hub
Front: Alloy, double sealed cartridge bearings, 15mm x 110mm Boost, Rear: Hope Pro 4, sealed stainless steel cartridge bearings, 12mm x 148mm Boost
Rims
WTB ST i35 TCS 2.0 System, pinned joint, tubeless ready, 32 hole
Spokes
DT Swiss Factory 2.0mm, black stainless, brass nipples
Tires
Front: Maxxis High Roller II TR 27.5 x 2.8" 120 tpi, EXO, 3C MaxxTerra, Rear: Maxxis Rekon TR 27.5 x 2.8" 60 tpi, EXO
Brakes
Brakes
Front: SRAM Guide R, 4-piston, 180mm rotor (S, M, L), 200mm rotor (XL), Rear: SRAM Guide R, 4-piston, 160mm rotor (S), 180mm rotor (M, L), 200mm rotor (XL)
Brake Levers
SRAM Guide R, MMX
Cockpit
Stem
Whyte Gravity, 35mm length
Handlebar
Whyte 6061 alloy, 31.8mm diameter, 760mm wide (S), 780mm wide (M, L, XL), 15mm rise (S, M), 30mm rise (L, XL)
Grips
Whyte Lock-on V
Headset
FSA No. 57E Orbit ZS, sealed cartridge bearings
Seat
Saddle
Whyte Custom, triple panel design
Seatpost
SDG Tellis dropper, paddle remote lever, 125mm (S), 150mm (M, L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm | 1.3 mm |
| Bottom Bracket Height | 297.5 mm | 297.5 mm | 297.5 mm | 297.5 mm |
| Stack | 630.4 mm | 639.4 mm | 650.4 mm | 657.4 mm |
| Reach | 433.4 mm | 460.4 mm | 482.4 mm | 507.4 mm |
| Top Tube Length | 606.4 mm | 633.4 mm | 660.4 mm | 688.4 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1167 mm | 1196 mm | 1230 mm | 1266 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 789 mm | 806 mm | 823 mm | 840 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
909 belongs to the Whyte 909 model. Whyte launched 8 bikes of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 12.9 kg (28.44 lbs), Whyte bike is slightly lighter than average. In other words, this model is 0.62% lighter than the average Trail bike.
909 components
Fork
Whyte 909 2019 bike is equipped with the Fox Performance Float 34 fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on 909 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Whyte 909 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
