Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Tapered Head Tube, Custom Drawn, Chainstay Flat Mount 160mm Disc Mount, BBX Cable Routing
Suspension Fork
Whyte Straight Bladed 6061 Alloy, Tapered Alloy Steerer, Internal Cable Routing, Flat Mount Dropouts, 12mm x 100mm Stealth Through Axle, Eyelets for Mudguards
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400, Shadow Plus, 10 Speed
Front Derailleur
Shimano GRX RD-RX400, 10 Speed
Shift Levers
Shimano GRX ST-RX600, 10 Speed
Cassette
SunRace CSMS1, 11-36, 10 Speed
Crank
Whyte, Forged Cranks, 2pcs, Super Compact Double 30-46t, 10 Speed, 170mm
Bottom Bracket
BSA, Cartridge Bearings, 68mm
Chain
SunRace CN10, Black, 10 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 100mm Through Axle, Centre-Lock, 32 Hole, Concealed Hex Key
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 142mm Through Axle, Centre-lock, 32 Hole
Rims
Whyte RG-7, Tubeless Ready, 32 Hole
Spokes
2.0mm, Black Stainless, Brass Nipples
Tires
Schwalbe G-ONE BITE, 700 x 40c, TL-Easy with RaceGuard puncture protection
Brakes
Brakes
Shimano GRX BR-RX400, 160mm Flat Mount, Internal Routing
Brake Levers
Shimano GRX ST-RX600, Hydraulic
Cockpit
Stem
Whyte Alloy, +-7° Rise, 48/50cm 60mm, 52cm 70mm, 54cm 80mm, 56/58cm 90mm Extension
Handlebar
Controltech, 6061 Alloy, Gravel/Road compact drop, 10mm riser bar, 31.8mm x 420mm 48cm, 440mm 50cm, 460mm 52&54cm, 480mm 56&58cm
Grips
Whyte Anti Slip, Cross Bar Tape
Headset
FSA No. 42, Integrated Road, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom
Seatpost
Whyte 6061 Alloy, 20mm Offset, 27.2mm x 350mm, 2 Bolt Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.43 mm | 1.45 mm | 1.4 mm | 1.41 mm | 1.4 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Stack | 546 mm | 558 mm | 572 mm | 586 mm | 600 mm | 615 mm |
| Reach | 386 mm | 391 mm | 395 mm | 420 mm | 425 mm | 440 mm |
| Top Tube Length | 543 mm | 552 mm | 561 mm | 590 mm | 599 mm | 618 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1025 mm | 1035 mm | 1045 mm | 1075 mm | 1085 mm | 1105 mm |
| Bottom Bracket Drop | 79 mm | 79 mm | 79 mm | 79 mm | 79 mm | 79 mm |
| Standover Height | 751 mm | 768 mm | 785 mm | 802 mm | 819 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
DEAN v1 is part of the Whyte Dean model. 4 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Whyte DEAN v1 price was 1642$. If we compare this with the average Gravel bike cost we notice that the price is 49.94% smaller.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
DEAN v1 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When leaving the production line, the DEAN v1 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
