Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Tapered Head Tube, Internal Cable Routing with BBX and Custom Whyte Dropouts, Chain Stay Kick Stand Mount
Suspension Fork
Whyte Straight Bladed 6061 Alloy, Alloy Tapered Steerer, Internal Cable Routing, 12mm Thru Axle, Post Mount with Single Eyelets for Mudguards
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore RD-M4120-SGS, Shadow Plus, 10 Speed
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M4100, 10 Speed
Cassette
Shimano Deore CS-M4100, 11-42, 10 Speed
Crank
2pcs Alloy, Narrow/Wide 42T Chainring with Guard, 10 Speed
Bottom Bracket
Sealed Cartridge Bearings, 68mm
Chain
Sunrace, 10 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 100mm Through Axle, 28 Hole, Concealed Hex Key
Rear Hub
Alloy, Cup & Cone, Double Seal, 32 Hole
Rims
Whyte Disc Road Plus 650b, Low Profile, 25mm Wide, Tubeless Compatible, 32 Hole Rear and 28 Hole Front
Spokes
2.0mm, PG, Black Stainless, Brass Nipples
Tires
WTB Horizon 650b x 47c, Tan Wall, Road Plus
Brakes
Brakes
Shimano MT200, Hydraulic, 160mm Disc, Internal Routing
Brake Levers
Shimano MT200
Cockpit
Stem
Whyte Alloy, S/M 45mm, L/XL 60mm
Handlebar
Whyte 6061 Alloy, 20mm Rise, 31.8mm, 620mm Wide
Grips
Whyte Custom Dual Density Lock-on
Headset
FSA No. 42, Integrated Road, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom
Seatpost
Whyte 6061 Alloy, 20mm Offset, 27.2mm x S/M/L 350mm, XL 400mm, 2 Bolt Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.36 mm | 1.37 mm | 1.39 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 271.5 mm | 271.5 mm |
| Stack | 618.4 mm | 585.4 mm | 599.4 mm | 618.4 mm |
| Reach | 415.4 mm | 430.4 mm | 438.4 mm | 446.4 mm |
| Top Tube Length | 575.8 mm | 601.6 mm | 619.4 mm | 633.3 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 444.5 mm | 495 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 145 mm | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1067 mm | 1084 mm | 1100 mm | 1115 mm |
| Standover Height | 722 mm | 751 mm | 795 mm | 823 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
PORTOBELLO v2 is part of the Whyte Portobello model. There are 5 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2021 and its price was 1004$. Comparing this to the average Commuter bike price, we see that the price is 31.76% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
PORTOBELLO v2 components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The PORTOBELLO v2 2021 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Whyte PORTOBELLO v2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
