Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Fox Performance Elite Float 34
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM G2 R Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, SCR Aluminium Front Triangle with Tapered Head Tube, ISCG 2 Guide Mounts, Alloy Symmetrical SCR Rear Triangle, Shape.it and 148mm Boost Dropouts
Suspension Fork
Fox Float 34 Performance Elite 29", 140mm Travel, 44mm Offset, Grip 2 Damper, Tapered Steerer, 110mm x 15mm Boost E-Thru Axle
Rear Shock
Fox DPS Performance Elite, Evol LV, Adjustable Rebound and 3 Position Compression, 210 x 50mm, custom tuned for Whyte
Drivetrain
Rear Derailleur
SRAM GX Eagle 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle Trigger MMX, 12 Speed
Cassette
SRAM XG-1275 Eagle, 10-52, 12 Speed
Crank
SRAM GX, Direct Mount 32T, DUB, 165mm
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM GX Eagle, 12 Speed
Pedals
None
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 9 deg Micro Engagement 4 Pawl, XD Driver, 32 Hole
Rims
Race Face AR-30, Offset, 30mm Wide, Sleeved Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Minion DHF TR 29" x 2.5" WT 60TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Dissector TR 29" x 2.4" WT 120TPI, EXO+ Sidewall Protection, 3C Maxx Terra, Rear
Brakes
Brakes
SRAM Guide G2 R, 4 Piston, 180mm Disc
Brake Levers
SRAM Guide G2 R, Matchmaker
Cockpit
Stem
Whyte Gravity Stem, 35mm Extension
Handlebar
Whyte 6061 Alloy, 31.8mm, 780mm Wide, M 20mm, L/XL 30mm Rise
Grips
Whyte Lock-on Enduro Grip
Headset
FSA No. 57 Orbit ZS, ACB, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Dual Density, Triple Panel Design
Seatpost
Whyte Drop.It II, 30.9mm, Adjust, M 120-150mm, L 140-170mm, XL 170-200mm Travel, Paddle Remote Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.445 mm | 1.392 mm | 1.339 mm | 1.291 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 752 mm | 782 mm | 817 mm | 849 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 121 mm | 121 mm | 121 mm | 121 mm |
| Stack | 621.4 mm | 633.2 mm | 646.8 mm | 658.5 mm |
| Reach | 430 mm | 455 mm | 483 mm | 510 mm |
| Seat Tube Angle | 76.4 ° | 76.2 ° | 76 ° | 75.8 ° |
| Seat Tube Length | 395 mm | 420 mm | 445 mm | 470 mm |
| Head Tube Angle | 65.3 ° | 65.3 ° | 65.3 ° | 65.3 ° |
| Head Tube Length | 107 mm | 120 mm | 135 mm | 148 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1184 mm | 1215 mm | 1249 mm | 1282 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 735 mm | 735 mm | 735 mm | 735 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
