Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Fork RockShox Lyrik
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes TRP Trail EVO Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, SCR Aluminium Front Triangle with Tapered Head Tube, ISCG 2 Guide Mounts, Alloy Symmetrical SCR Rear Triangle, Shape.it and 148mm Boost Dropouts
Suspension Fork
RockShox Lyrik 29", 160mm Travel, 44mm Offset, DebonAir+, Rush RC Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear Shock
RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position Compression, 210 x 55mm, custom tuned for Whyte
Drivetrain
Rear Derailleur
Shimano M6100 Deore, SGS, Shadow Plus, 12 speed
Front Derailleur
N/A
Shift Levers
Shimano M6100 Deore, I-Spec EV, 12 speed,
Cassette
Sunrace CSMZ901, 11-51, Black, 12 speed
Crank
Whyte, Forged 2pcs Cranks, Direct Mount alloy 32T Narrow wide Chainring, 170mm, Boost, 12 speed
Bottom Bracket
BSA, Cartridge Bearings, 73mm
Chain
Shimano M6100, 12 speed
Pedals
None
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Rims
WTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Assegai TR 29" x 2.5" 60TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Minion DHR II TR 29" x 2.4" WT 120TPI, EXO+ Sidewall Protection, Dual Compound, Rear
Brakes
Brakes
TRP Trail Evo, 4 Piston with Sintered Metal Pads, 203mm 2.3mm Disc
Brake Levers
TRP Trail Evo
Cockpit
Stem
Whyte Gravity Stem, 35mm Extension
Handlebar
Whyte Custom 6061 Alloy, 20mm Rise, 35mm, 800mm Wide
Grips
Whyte Lock-on Enduro Grip
Headset
FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Dual Density, Triple Panel Design
Seatpost
Whyte drop.it Post II Adjust, 30.9mm, M/L 140-170mm Travel, XL 170-200mm Travel, Shimano Remote Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.404 mm | 1.349 mm | 1.305 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm |
| Front Center | 783 mm | 817 mm | 851 mm |
| Rake | 43 mm | 43 mm | 44 mm |
| Trail | 129 mm | 129 mm | 128 mm |
| Stack | 632 mm | 645 mm | 659 mm |
| Reach | 450 mm | 478 mm | 505 mm |
| Seat Tube Angle | 75.1 ° | 74.8 ° | 74.6 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 64.7 ° | 64.7 ° | 64.7 ° |
| Head Tube Length | 100 mm | 125 mm | 140 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1222 mm | 1256 mm | 1290 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm |
| Standover Height | 825 mm | 828 mm | 839 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
