Wilier Filante Hybrid SRAM FORCE D2 AXS 2X12 + MAHLE X20 2024
2024 E-bike
Estimate price |
10,819$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force, Force eTap -
Suspension Rigid -
Motor 55Nm mid-drive -
Battery 236 WH, 36 V, ANT+ CONNECTIVITY -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Suspension Fork
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Drivetrain
Rear Derailleur
SRAM FORCE eTAP AXS RD-FRC-E-D2
Front Derailleur
SRAM FORCE eTAP AXS FD-FRC-E-D2
Shift Levers
SRAM FORCE eTAP AXS HRD SHIFT
Cassette
SRAM FORCE CS-XG-1270-D2 10-28T
Crank
SRAM FORCE FC-FRC-D2 48-35T
Bottom Bracket
SRAM DUB PRESSFIT BB-DUB-PF-A1
Chain
SRAM FORCE CN-FRC-D2
Wheels
Rims
WILIER HY-NDR28AC
Tires
VITTORIA RUBINO 700X28
Brakes
Brakes
SRAM BRAKE SYSTEM ED-FRC-D2 2x12
Cockpit
Handlebar
FILANTE HY BAR INTEGRATED CARBON
Headset
WILIER CUSTOM BEARINGS SUPERSLIM
Seat
Saddle
PROLOGO DIMENSION 143
Seatpost
FILANTE CUSTOM MADE -15 mm/0 mm
Motor & Battery
Motor
55 Nm
Battery
236 WH, 36 V, ANT+ CONNECTIVITY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.428 mm | 1.46 mm | 1.493 mm | 1.526 mm | 1.553 mm | 1.582 mm |
| Stack | 527 mm | 546 mm | 566 mm | 586 mm | 604 mm | 625 mm |
| Reach | 369 mm | 374 mm | 379 mm | 384 mm | 389 mm | 395 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Wheelbase | 977 mm | 985 mm | 995 mm | 1002 mm | 1013 mm | 1027 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
