Wilier GTR Team SHIMANO 105 R7020 11s 2024
2024 Road
Estimate price |
2,908$
Weight | 9.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GTR TEAM DISC - CARBON MONOCOQUE 46TON
Suspension Fork
GTR TEAM DISC - CARBON MONOCOQUE 46TON
Drivetrain
Rear Derailleur
SHIMANO 105 RD-R7000-SS
Front Derailleur
SHIMANO 105 FD-R7000
Shift Levers
SHIMANO 105 ST-R7020
Cassette
SHIMANO 105 CS-R7000 11-30T
Crank
SHIMANO 105 FC-R7000 50-34T
Bottom Bracket
SHIMANO PRESSFIT SM-BB71-41
Chain
SHIMANO CN-HG600-11
Wheels
Rims
SHIMANO RS171
Tires
VITTORIA ZAFFIRO PRO 4 700X25
Brakes
Brakes
SHIMANO 105 BR-R7070
Cockpit
Stem
ZOOM STEM TDS-RD507
Handlebar
ZOOM H-BAR DR-AL210
Headset
RITCHEY COMP TAPERED PRD18228
Seat
Saddle
SELLE ITALIA MODEL X
Seatpost
ZOOM SEATPOST 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.381 mm | 1.405 mm | 1.431 mm | 1.459 mm | 1.48 mm | 1.509 mm |
| Stack | 515 mm | 531 mm | 548 mm | 566 mm | 583 mm | 602 mm |
| Reach | 373 mm | 378 mm | 383 mm | 388 mm | 394 mm | 399 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72 ° | 72.5 ° |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
