Wilier Karga SHIMANO DEORE XT 1X12S + SHIMANO EP801 2025
2025 E-bike
Estimate price |
10,354$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Fork RockShox ZEB Select+
-
Groupset XT -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery SIMPLO TPS-002 in-tube battery pack 720 Wh -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 172cm
MD
169cm - 177cm
LG
174cm - 186cm
XL
183cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CARBON FRONT TRIANGLE, ALLOY REAR STAYS
Suspension Fork
ROCK SHOX 38 ZEB SELECT PLUS FS-ZEB-SELP-A3 160 mm
Drivetrain
Rear Derailleur
SHIMANO DEORE XT RD-M8100-SGS
Shift Levers
SHIMANO DEORE XT 1X12 SL-M8100
Cassette
SHIMANO DEORE XT CSM8100-12 10-51T
Crank
SHIMANO FC-EM600
Bottom Bracket
SHIMANO EP801 DRIVE UNIT INTEGRATED AXLE
Chain
SHIMANO XT CN-M7100
Wheels
Rims
SHIMANO MT620 ALLOY 29" TLR
Tires
VITTORIA MAZZA 29X2.4" TLR
Brakes
Brakes
SHIMANO DEORE XT BR-M8120 4 PISTONS
Cockpit
Stem
FSA GRADIENT
Handlebar
FSA GRADIENT ALLOY
Headset
TOKEN
Seat
Saddle
ERGONOMIC DESIGN
Seatpost
KS LEV-Si 100 DROPPER ? 27.2 mm
Motor & Battery
Motor
SHIMANO MID-DRIVE DU-EP801 85 Nm
Battery
SIMPLO TPS-002 in-tube battery pack 720 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.378 mm | 1.321 mm | 1.269 mm |
| Stack | 620 mm | 627 mm | 634 mm | 641 mm |
| Reach | 430 mm | 455 mm | 480 mm | 505 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 420 mm | 440 mm | 460 mm | 480 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Wheelbase | 1213 mm | 1241 mm | 1269 mm | 1298 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 169 cm | 174 cm | 183 cm |
| Rider Max Height | 172 cm | 177 cm | 186 cm | 194 cm |
