Wilier Rave SL SHIMANO GRX 1X12S 2025
2025 Road
Estimate price |
4,886$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Shimano GRX 400 Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RAVE SL - CARBON MONOCOQUE NHU-MOD + HIGH IMPACT STRENGHT
Suspension Fork
RAVE SL - CARBON MONOCOQUE NHU-MOD + HIGH IMPACT STRENGHT
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX822-GS
Shift Levers
SHIMANO GRX ST-RX610
Cassette
SHIMANO CS-M7100-12 10-45T
Crank
SHIMANO GRX FC-RX610 40T
Bottom Bracket
MICHE PRESSFIT 86.5X41
Chain
SHIMANO CN-M6100
Wheels
Rims
MICHE GRAFF XL 700c TLR ALLOY
Tires
VITTORIA TERRENO DRY 700X40c TLR
Brakes
Brakes
SHIMANO GRX BR-RX400
Cockpit
Stem
RITCHEY | WILIER STEMMA ALLOY
Handlebar
RITCHEY COMP ERGOMAX ALLOY
Headset
CUSTOM SUPERSLIM 1-1/8" UPPER BR | FSA MR137 1-1/4" LOWER BR
Seat
Saddle
SELLE SAN MARCO SHORTFIT 2.0 OPEN-FIT NARROW
Seatpost
WILIER FILANTE CARBON CUSTOM MADE -15 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.411 mm | 1.435 mm | 1.458 mm | 1.48 mm | 1.501 mm |
| Stack | 513 mm | 532 mm | 551 mm | 570 mm | 589 mm | 608 mm |
| Reach | 370 mm | 377 mm | 384 mm | 391 mm | 398 mm | 405 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Wheelbase | 997 mm | 1012 mm | 1017 mm | 1031 mm | 1041 mm | 1051 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
