winora Domingo 27 2025
2025 Urban
Estimate price |
1,220$
Weight | 16 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour NEX -
Groupset Alivio, Acera -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
48cm
162cm - 170cm
52cm
168cm - 178cm
56cm
176cm - 186cm
60cm
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Aluminium Gents
Suspension Fork
Suntour NEX DS-HLO
Drivetrain
Rear Derailleur
Shimano Alivio M3100
Front Derailleur
Shimano Acera T3000
Shift Levers
Shimano Alivio M3100
Cassette
Shimano HG200
Crank
Shimano Alivio T4010
Bottom Bracket
Shimano BB52
Chain
Shimano Chain HG95
Wheels
Front Hub
Shimano hub dynamo 3D32
Rear Hub
alu hub
Rims
Rodi Hollow rim Black Rock 21
Tires
XLC TourX 42-622
Brakes
Brakes
Alhonga Hydraulic Disc brake HT474
Cockpit
Stem
Alu
Handlebar
Ergobar, oversize
Headset
VP B307AC
Seat
Saddle
Selle Royal Wave
Seatpost
Non Suspension
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 56cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.515 mm | 1.493 mm | 1.487 mm | 1.487 mm |
| Front Center | 644 mm | 659 mm | 675 mm | 691 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 76 mm | 76 mm | 76 mm |
| Stack | 606 mm | 615 mm | 629 mm | 644 mm |
| Reach | 400 mm | 412 mm | 423 mm | 433 mm |
| Top Tube Length | 585 mm | 600 mm | 615 mm | 630 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 135 mm | 145 mm | 160 mm | 175 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1087 mm | 1102 mm | 1118 mm | 1134 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 770 mm | 785 mm | 810 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 168 cm | 176 cm | 184 cm |
| Rider Max Height | 170 cm | 178 cm | 186 cm | 194 cm |
