Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery Mahle SmartBike Systems InTube, 250 Wh -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, hydroformed, Aluminium 6061
Suspension Fork
Winora, Carbon, 12 x 100mm thru-axle
Drivetrain
Rear Derailleur
Shimano, Deore M4120
Shift Levers
Shimano, Deore M4100, Trigger switch
Cassette
Shimano, CSM4100, 11 - 42 teeth
Crank
Samox, Aluminium
Bottom Bracket
Samox, EB2405, BSA
Chain
KMC, e10S
Pedals
Marwi, SP-880, mit Reflektor
Wheels
Rims
Ryde, Rival19, With Eyelets, Double Wall, Aluminium
Spokes
Sapim, Leader
Tires
Continental, Contact Urban, 50-584, 27.5 x 2.0 inch
Brakes
Brakes
Rim
Brake Levers
Tektro, R280, Aluminium
Cockpit
Stem
Alu, A-head, 31.8 mm
Handlebar
Topflat, 640 mm
Grips
Herrmans, Single Lock Griffe
Headset
Acros, AIX-532, Aluminium
Seat
Saddle
Selle Royal, VivoErgo
Seatpost
Aluminium, Patent, 27.2 mm
Motor & Battery
Motor
Mahle SmartBike Systems X35+, 250W, 40Nm
Battery
Mahle SmartBike Systems InTube, 250 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 55cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.409 mm | 1.451 mm | 1.525 mm | 1.562 mm |
| Stack | 517 mm | 547 mm | 578 mm | 606 mm |
| Reach | 367 mm | 377 mm | 379 mm | 388 mm |
| Top Tube Length | 525 mm | 544 mm | 561 mm | 579 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 90 mm | 120 mm | 150 mm | 180 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 650 | 650 | 650 | 650 |
About this model
E-Flitzer is part of the Winora E E Flitzer model. Winora launched 1 e-bike of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter e-bikes average price
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2752$. If we compare this with the average Commuter e-bike cost we notice that the price is 7.12% more expensive.
E-Flitzer components
Fork material
E-Flitzer has a carbon fork, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the E-Flitzer e-bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Winora E-Flitzer has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
