Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Li-ION, Capacity: 750Wh, Location: Powertube -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 170cm
MD
167cm - 177cm
LG
174cm - 183cm
XL
180cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Gents
Suspension Fork
Koga Non Suspension KOGA Rigid, 27,5", 15x100, 1 1/8 -1 1/2, Postmount
Drivetrain
Shift Levers
Enviolo Gripshift Twist Pro Display, Multi-Turn, 2500mm
Cassette
Gates Sprocket CDX, For Enviolo, RVS
Crank
Koga single Gen4, ISIS
Chain
Gates Belt CDX, 122T
Chain Guide
Koga Chainshield Winning B10
Wheels
Front Hub
Formula Thru Axle 15mm Boost DC-711, 6-bolt, 32H
Rear Hub
Enviolo Vast Trekking, 6-bolt, 32H
Rims
Rodi Clincher TRYP 30, Disc Brake, 32H, W 30mm - H 19mm
Tires
Schwalbe Super Moto-X, DD greenGuard, With Reflection, E-50 62-584
Brakes
Brakes
Formula Hydraulic Disc brake
Cockpit
Stem
Satori Adjustable AIS, 31,8 - 55mm
Handlebar
Koga Trekking TR28AL, 31,8x640mm
Headset
Koga Semi-integrated Above 11/8 / Under 11/2
Seat
Saddle
Selle Royal City Vivo Ergo Sport - Gents
Seatpost
Satori Non Suspension
Motor & Battery
Motor
Bosch Performance Line CX (Smart System)
Battery
Bosch Li-ION, Capacity: 750Wh, Location: Powertube
Charger
Bosch Quick Charger 4A / 230V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.385 mm | 1.389 mm | 1.394 mm | 1.419 mm |
| Front Center | 754 mm | 762 mm | 771 mm | 783 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 35 mm | 35 mm | 33 mm | 32 mm |
| Stack | 651 mm | 660 mm | 669 mm | 688 mm |
| Reach | 470 mm | 475 mm | 480 mm | 485 mm |
| Top Tube Length | 657 mm | 664 mm | 672 mm | 682 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 470 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 180 mm | 190 mm | 200 mm | 220 mm |
| Chainstay Length | 484 mm | 484 mm | 484 mm | 484 mm |
| Wheelbase | 1233 mm | 1241 mm | 1250 mm | 1262 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 159 cm | 167 cm | 174 cm | 180 cm |
| Rider Max Height | 170 cm | 177 cm | 183 cm | 190 cm |
