Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour X1
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTube 800Wh, Capacity: 800 Wh, Location: Downtube -
Drivetrain 1 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Low Aluminium
Suspension Fork
Suntour X1 Air 80 mm
Drivetrain
Rear Derailleur
Shimano Cues U6000
Shift Levers
Shimano Cues SL-U6000 Rapidfire
Cassette
Shimano Cues LG300-10
Chain
Shimano Chain Cues LG500
Pedals
VP VPE-461
Wheels
Front Hub
Shimano HB-TC500 15x110 mm
Rear Hub
Shimano FH-TC500 12x148mm
Rims
Schürmann Yak25
Tires
Schwalbe AI Grounder Performance Reflex 60-584
Brakes
Brakes
Shimano
Cockpit
Stem
Satori Adjustable TDS-673-E90 31.8mm
Handlebar
Ergo Sport 680mm
Headset
Feimin A-Head FP-H858 Tapered Aluminium
Seat
Saddle
Selle Royal Vivo Ergo
Seatpost
JD Non Suspension SP20T 1A, Dia. 34.9 mm
Motor & Battery
Motor
Bosch Performance Line CX (Smart System)
Battery
Bosch PowerTube 800Wh, Capacity: 800 Wh, Location: Downtube
Charger
Bosch Fast Charger 4A
