Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour NEX -
Groupset Nexus -
Suspension Hardtail -
Motor Yamaha mid-drive -
Battery Li-ION InTube, Capacity: 630 Wh, Location: Powertube -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
46cm
161cm - 172cm
50cm
170cm - 179cm
54cm
177cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Low Aluminium Damesmono
Suspension Fork
Suntour NEX E25-HLO
Drivetrain
Shift Levers
Shimano Nexus
Cassette
Gates sprocket
Bottom Bracket
integrated in the motor
Chain
Gates Belt CarbonDrive
Pedals
VP E461
Wheels
Front Hub
aluminium hub
Rear Hub
Shimano Nexus
Rims
Schurmann Hollow rim Yak25
Tires
Continental Contact Cruiser 62-584
Brakes
Brakes
Shimano Hydraulic Disc brake
Cockpit
Stem
Adjustable aluminium, angle ajustable
Handlebar
Ergoriser, oversize
Headset
Cane Creek Viscoset
Seat
Saddle
Selle Royal Essenza
Seatpost
XLC Suspension
Motor & Battery
Motor
Yamaha PW-ST Series
Battery
Li-ION InTube, Capacity: 630 Wh, Location: Powertube
Charger
Yamaha Quick Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.419 mm | 1.4 mm | 1.426 mm |
| Front Center | 684 mm | 705 mm | 716 mm |
| Rake | 27 mm | 27 mm | 26 mm |
| Trail | 95 mm | 95 mm | 96 mm |
| Stack | 637 mm | 651 mm | 670 mm |
| Reach | 449 mm | 465 mm | 470 mm |
| Top Tube Length | 620 mm | 640 mm | 650 |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1153 mm | 1174 mm | 1185 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 161 cm | 170 cm | 177 cm |
| Rider Max Height | 172 cm | 179 cm | 190 cm |
