Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
142cm - 167cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
- Frame material: lightweight, high-quality AA 6061 aluminum with butted tubes, - Wheel size: 20" front, 26" rear, - Agile handling: The low center of gravity (created by the smaller front wheel) and upright riding position ensure stable balance, confident handling, an optimal view of the road, and a relaxed ride (even when loaded with a heavy school bag).
Suspension Fork
- Lightweight aluminum unicrown fork, - 1 ?" steerer, - Fork angle optimized for agile handling when fully loaded, - Flat mount for disc brake
Wheels
Rims
- Lightweight aluminum rims, - Shutter Precision SD-8 dynamo front hub, quick-release skewer for easy installation and removal of front wheel, - Aluminum rear hub with sealed industrial-grade bearings, - Double-crossed stainless-steel spokes (20 on front wheel, 28 on rear wheel)
Tires
- Schwalbe Big Apple balloon tires with RaceGuard puncture protection, - Front 20" x 2.15" folding bead tire / Rear 26" x 2.15" folding bead tire, - Premium, super-wide tires with natural dampening thanks to their large air volume, - Car-type (Schrader) valves allow the tires to be pumped up at gas stations, - Reflective stripe on the sidewalls for increased visibility in low-light conditions
Brakes
Brakes
- Flat mount hydraulic disc brakes from Promax or C-Star (depending on availability), - Disc diameter front/back: 140/140 mm, - Ergonomic brake levers designed for children's hands, - Rear disc brakes protected within the frame to prevent damage
Cockpit
Stem
- Ultralight stem made out of forged aluminum, - 40 mm length / +15°, - Knee-friendly design with recessed clamp bolts and a sleek, rounded design, - Two hexagon socket bolts attaching handlebars to stem, - Integrated star nut and bolt
Handlebar
- Wide, ergonomic, and lightweight aluminum bars with 15° backsweep for control and a natural arm position, - Sandblasted and anodized in black, - Width: 620 mm, - Rise: 33 mm
Grips
- woom Ergogrips with a small, child-friendly diameter, - Ergonomic surface, - Oversized grip ends for greater protection, - Lock-on design attaches grips securely to the bars
Headset
- Integrated 1 ?? headset, - Sealed industrial-grade bearings, - Integrated Ahead clamp
Seat
Saddle
- Ultra-comfy, - Ergonomic and age-specific design, - Water-repellent surface, no sponge effect, - Anti-abrasion material on the sides
Seatpost
- Anodized aluminum seatpost with minimum insertion depth and current saddle position marked
Fit data
Geometry
