Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Float 38
-
Groupset GX Eagle -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery SHIMANO 630Wh INTERNAL BATTERY -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TURQ Series carbon fiber frame, Sixfinity suspension technology, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle.
Suspension Fork
FOX PERFORMANCE 38/170MM E-TUNE
Rear Shock
FOX PERFORMANCE FLOAT X
Drivetrain
Rear Derailleur
SRAM GX EAGLE
Shift Levers
SRAM GX EAGLE
Cassette
SRAM GX EAGLE 1275 10-52
Crank
SHIMANO 34T
Bottom Bracket
N/A
Chain
SRAM GX EAGLE
Wheels
Rims
DT SWISS H1900 30MM
Tires
Front: MAXXIS ASSEGAI 2.5 EXO+, Rear: MAXXIS MINION DHR II 2.4 DD
Brakes
Brakes
SRAM CODE R
Cockpit
Stem
BURGTEC ENDURO MK3 35X50MM
Handlebar
YETI CARBON 35X800MM
Grips
ODI ELITE PRO
Headset
CANE CREEK 40 INTEGRATED
Seat
Saddle
SILVERADO CUSTOM
Seatpost
ONEUP DROPPER POST 31.6MM / SM: 180MM, MD: 210MM, LG-XL: 240MM
Motor & Battery
Motor
SHIMANO EP801
Battery
SHIMANO 630Wh INTERNAL BATTERY
Charger
SHIMANO E6002
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.435 mm | 1.348 mm | 1.302 mm | 1.257 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 762.3 mm | 793.7 mm | 816.1 mm | 845.9 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 617 mm | 620 mm | 625 mm | 635 mm |
| Reach | 430 mm | 460 mm | 480 mm | 505 mm |
| Top Tube Length | 561 mm | 592 mm | 614 mm | 642 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 380 mm | 410 mm | 450 mm | 495 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 95 mm | 98.3 mm | 103.8 mm | 114.9 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1208 mm | 1239 mm | 1262 mm | 1291 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm | 24 mm |
| Standover Height | 754 mm | 754 mm | 754 mm | 754 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
