Yeti SB135 T/Series Frameset 2025
2025 Mountain
Estimate price |
4,300$
Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Suspension Full
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle.
Rear Shock
FOX FACTORY FLOAT
Drivetrain
Bottom Bracket
BSA, 73mm, threaded
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.458 mm | 1.377 mm | 1.298 mm | 1.265 mm | 1.222 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 699 mm | 733 mm | 766 mm | 790 mm | 820 mm |
| Rake | 38 mm | 37 mm | 38 mm | 38 mm | 39 mm |
| Trail | 120 mm | 122 mm | 121 mm | 121 mm | 120 mm |
| Stack | 583 mm | 592 mm | 597 mm | 606 mm | 616 mm |
| Reach | 400 mm | 430 mm | 460 mm | 479 mm | 504 mm |
| Top Tube Length | 534 mm | 566 mm | 598 mm | 620 mm | 647 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 76.9 ° |
| Seat Tube Length | 345 mm | 365 mm | 400 mm | 440 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.4 ° | 65.4 ° | 65.4 ° | 65.4 ° |
| Head Tube Length | 92 mm | 101 mm | 107 mm | 118 mm | 129 mm |
| Chainstay Length | 429 mm | 431 mm | 433 mm | 435 mm | 437 mm |
| Wheelbase | 1128 mm | 1164 mm | 1199 mm | 1225 mm | 1257 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 675 mm | 678 mm | 714 mm | 718 mm | 722 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
