yt Industries Izzo 29 CORE 3 CF 2025
2025 Mountain
Estimate price |
5,234$
Weight | 14.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Travel Rear 130mm -
Fork Öhlins RXF36
-
Groupset XT, SLX -
Suspension Full -
Brakes Shimano SLX Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 168cm
MD
166cm - 178cm
LG
175cm - 186cm
XL
184cm - 194cm
XXL
192cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
ÖHLINS RXF36 M.3
Rear Shock
ÖHLINS TTX1 AIR
Drivetrain
Rear Derailleur
SHIMANO SLX RD-M7100
Shift Levers
SHIMANO XT SL-M8100
Cassette
SHIMANO SLX CS-M7100
Crank
SHIMANO SLX FC-M7120
Bottom Bracket
SHIMANO BB-MT800-PA
Wheels
Rims
DT SWISS XM1700
Tires
MAXXIS MINION DHR II
Brakes
Brakes
SHIMANO SLX
Cockpit
Stem
RENTHAL APEX 35
Handlebar
RENTHAL FATBAR 35 AL
Grips
ODI ELITE MOTION V2.1
Headset
ACROS AZX
Seat
Saddle
SDG BEL AIR OVERLAND 3.0
Seatpost
YT POSTMAN V2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.406 mm | 1.36 mm | 1.316 mm | 1.291 mm | 1.255 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm | 339 mm |
| Stack | 603 mm | 612 mm | 621 mm | 635 mm | 644 mm |
| Reach | 429 mm | 450 mm | 472 mm | 492 mm | 513 mm |
| Top Tube Length | 566 mm | 591 mm | 616 mm | 641 mm | 666 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 475 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 437 mm | 437 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 734 mm | 727 mm | 721 mm | 716 mm | 734 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 166 cm | 175 cm | 184 cm | 192 cm |
| Rider Max Height | 168 cm | 178 cm | 186 cm | 194 cm | 204 cm |
