yt Industries Izzo CORE 2 29 2024
2024 Mountain
Estimate price |
3,784$
Weight | 14.6 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 168cm
MD
166cm - 178cm
LG
175cm - 186cm
XL
184cm - 194cm
XXL
192cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
FOX 34 FLOAT PERFORMANCE, 29“ | 130 mm Travel | 110 x 15 mm QR Axle | 44 mm Offset | Grip Damper, Adjustable Low-Speed Compression and Rebound, Air Pressure
Rear Shock
FOX FLOAT PERFORMANCE, Shock Length: 210 mm | Shock Stroke: 55 mm ? 130 mm Travel | 2-pos lever, 0.2 Spacer, custom tune
Drivetrain
Rear Derailleur
SRAM NX EAGLE, 12-speed
Shift Levers
SRAM NX EAGLE, 12-speed I MMX
Cassette
SRAM XG 1230 Eagle, 11-50T | 12-speed
Crank
SRAM NX EAGLE, Crank Arm Length 170 mm (S), 175 mm (M-XXL) | 32T | DUB
Bottom Bracket
SRAM DUB Pressfit, BB DUB PF 92 MTB
Wheels
Rims
CRANKBROTHERS SYNTHESIS XCT ALLOY, Aluminium rims 29” | Front: Inner Width 26.5mm | 110 x 15mm | 6-Bolt, Rear: Inner Width 24.5mm | 148 x 12mm | 6-Bolt | Freehub HG
Tires
MAXXIS MINION DHR II, Front: 29’’ x 2.4 WT I 3C MaxxTerra I EXO I TR, Rear: 29’’ x 2.4 WT I Dual Compound I EXO I TR
Brakes
Brakes
SRAM G2 R, Rotor CENTERLINE Ø front 200 mm / rear 180 mm | Adjustable Reach
Cockpit
Stem
RACE FACE AEFFECT R 35, Length 50 mm (S-M), 60 mm (L-XXL) | 35 mm Clamp | Rise +/-6°
Handlebar
RACE FACE AEFFECT R 35, Width 780 mm | Rise 20 mm | 9° Back Sweep | 5° Up Sweep | 7075 AL
Grips
ODI ELITE MOTION V2.1, Lock On
Headset
ACROS AZX, 586 Block Lock (S-M), 576 (L-XXL) I 2 Spacer 5 mm
Seat
Saddle
SDG BEL AIR Overland 3.0, YT Custom | Width 140 mm I Lux-Alloy Rail
Seatpost
YT POSTMAN V2, Ø 31,6mm I MMX-Remote | Adjustable drop 25/10/5mm | 100 mm (S) I 125 mm (M) | 150 mm (L) | 170 mm (XL) | 200mm (XXL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.406 mm | 1.36 mm | 1.316 mm | 1.291 mm | 1.255 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 728 mm | 753 mm | 779 mm | 805 mm | 830 mm |
| Rake | 42 mm | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 121 mm | 121 mm | 121 mm | 122 mm | 122 mm |
| Stack | 603 mm | 612 mm | 621 mm | 635 mm | 644 mm |
| Reach | 429 mm | 450 mm | 472 mm | 492 mm | 513 mm |
| Top Tube Length | 566 mm | 591 mm | 616 mm | 641 mm | 666 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 475 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 130 mm | 140 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 437 mm | 437 mm |
| Wheelbase | 1158 mm | 1183 mm | 1209 mm | 1240 mm | 1265 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 734 mm | 727 mm | 721 mm | 716 mm | 734 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 166 cm | 175 cm | 184 cm | 192 cm |
| Rider Max Height | 168 cm | 178 cm | 186 cm | 194 cm | 204 cm |
