yt Industries Tues CORE 2 MX 2024
2024 Mountain
Estimate price |
4,652$
Weight | 16.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
162cm - 176cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
ROCKSHOX BOXXER BASE, 29“ | 200mm | Charger 3 RC | 110 x 20mm | 52mm Offset
Rear Shock
ROCKSHOX SDLX SELECT COIL, Shock Length: 250 mm | Shock Stroke: 75 mm | Rebound Adjust | Hydraulic Bottom Out | LNLC | 300 lbs (S) | 350 lbs (M)
Drivetrain
Rear Derailleur
SRAM GX DH, 7-Speed | Medium Cage
Shift Levers
SRAM GX DH, 7-Speed | MMX
Cassette
SRAM PG-720 DH, 7-Speed | 11-25T
Crank
SRAM GX DH, 165 mm | 34T Custom | DUB
Bottom Bracket
SRAM DUB BSA, BB DUB BSA 83 DH
Chain Guide
E13 LG1 Plus, I05 | Compact Slider | 32 - 34 T
Wheels
Rims
SUNRINGLE DUROC SD37 COMP, Front: 29’’ 32 mm I 110 x 20 mm I 6-Bolt, Rear: 27,5’’ 32 mm | 148 x 12 mm I 6-Bolt | HG
Tires
MAXXIS ASSEGAI DH, Front: 29’’ x 2.5 WT I 3C MaxxGrip I DH I TR, Rear: 27.5’’ x 2.5 WT | 3C MaxxGrip I DH I TR
Brakes
Brakes
SRAM DB8, Maxima Mineral Oil | Centerline 220 / 220mm
Cockpit
Stem
RACE FACE CHESTER 35, Length 50mm | 0 Rise | 6061 AL | Black
Handlebar
RACE FACE CHESTER 35, 780 mm | 35mm Rise | 8° Back | 5° Up | 6061 AL | Black
Grips
ODI ELITE MOTION V2.1, Lock On
Headset
ACROS AZX-255, ZS49 ZS56 | High Cap
Seat
Saddle
SDG I-FLY 2.0, YT Custom | Width 128mm I I-Beam
Seatpost
SDG I-Beam Alloy, Ø 31.6mm | 300mm Length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.491 mm | 1.435 mm |
| Bottom Bracket Height | 346 mm | 346 mm |
| Front Center | 793 mm | 815 mm |
| Rake | 54 mm | 53 mm |
| Trail | 129 mm | 130 mm |
| Stack | 635 mm | 640 mm |
| Reach | 426 mm | 446 mm |
| Top Tube Length | 581 mm | 603 mm |
| Seat Tube Angle | 76.3 ° | 76.2 ° |
| Seat Tube Length | 390 mm | 390 mm |
| Head Tube Angle | 63.2 ° | 63.2 ° |
| Head Tube Length | 100 mm | 105 mm |
| Chainstay Length | 439 mm | 439 mm |
| Wheelbase | 1230 mm | 1252 mm |
| Bottom Bracket Drop | 30 mm | 30 mm |
| Standover Height | 727 mm | 731 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 154 cm | 162 cm |
| Rider Max Height | 166 cm | 176 cm |
