Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Exploro PRIMO
Suspension Fork
3T Fango
Drivetrain
Rear Derailleur
SRAM Rival 1 long cage
Front Derailleur
-
Shift Levers
SRAM Rival1 Hydraulic DoubleTap
Cassette
11-speed SRAM Rival 11-42T
Crank
FSA Omega BB386EVO or SRAM Rival depending on availability, 40T chainring ( XXS: 165mm - 51: 170mm - 54&56: 172,5mm - 58&61: 175mm)
Bottom Bracket
BB86/BB92, press-fit
Wheels
Rims
Fulcrum Rapid Red 900, 700c, tubeless ready (upgrade to 3T Discus 45|40, 45|32, Plus i28 possible)
Tires
–
Brakes
Brakes
SRAM Rival Flat Mount Hydraulic Disc w/ SRAM 160mm
Cockpit
Stem
APTO STEALTH
Handlebar
–
Headset
Sealed cartridge 1.125” - 1.5”
Seat
Saddle
–
Seatpost
3T Exploro seatpost for Ritchey clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 591 mm | 598 mm | 606 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 67 mm | 58 mm | 58 mm |
| Stack | 512 mm | 541 mm | 570 mm | 599 mm |
| Reach | 361 mm | 373 mm | 385 mm | 397 mm |
| Top Tube Length | 524 mm | 545 mm | 566 mm | 587 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 463 mm | 490 mm | 518 mm | 545 mm |
| Head Tube Angle | 69.5 ° | 71.1 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 101 mm | 125 mm | 150 mm | 180 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 991 mm | 998 mm | 1006 mm | 1027 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 168 cm | 178 cm | 188 cm |
Model Overview
Exploro Primo Rival 1×11 is part of the 3t Exploro Primo model. 6 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the 3T Exploro Primo Rival 1×11 2023 has a starting price of 3299$. 3T Exploro Primo Ekar 1×13 Levante 2023 on the other hand is the most expensive at 5096$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, 3T Exploro Primo Rival 1×11 price was 3299$. If we compare this with the average Gravel bike cost we notice that the price is 34% higher.
Exploro Primo Rival 1×11 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Exploro Primo Rival 1×11 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
