Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3T Strada Integrale 1X (seattube optimized for no FD mount inserts)
Suspension Fork
3T Fundi Integrale
Drivetrain
Rear Derailleur
SRAM Rival AXS XPLR max 44T
Front Derailleur
-
Shift Levers
SRAM Rival AXS
Cassette
12-speed Rival XPLR, 10-44T
Crank
SRAM Rival AXS Wide, 40T chainring (XXS: 165mm - 51: 170mm - 54&56: 172,5mm - 58&61: 175mm)
Wheels
Rims
Fulcrum Rapid Red 900, 700c, 22mm internal width, tubeless ready (upgrade to 3T Discus 45|32 LTD possible)
Tires
–
Brakes
Brakes
SRAM Rival AXS Hydraulic Disc w/ SRAM 160mm rotor
Cockpit
Stem
3T Apto Integrale Stealth (XXS: 80mm - 51: 90mm - 54:100mm - 56: 110mm - 58: 120mm)
Handlebar
–
Headset
3T MinMax Integrale IS42/34 | IS47/38(36deg)
Seat
Saddle
–
Seatpost
Strada Seatpost for Ritchey Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.4 mm | 1.44 mm | 1.46 mm |
| Bottom Bracket Height | 265 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 567 mm | 574 mm | 580 mm | 596 mm | 616 mm |
| Rake | 49 mm | 47 mm | 47 mm | 47 mm | 46 mm |
| Trail | 73 mm | 66 mm | 55 mm | 52 mm | 53 mm |
| Stack | 503 mm | 509 mm | 538 mm | 567 mm | 596 mm |
| Reach | 351 mm | 371 mm | 383 mm | 395 mm | 407 mm |
| Top Tube Length | 509 mm | 531 mm | 552 mm | 573 mm | 594 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 487 mm | 500 mm | 506 mm | 518 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 71 ° | 72.7 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 119 mm | 119 mm | 143 mm | 172 mm | 202 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 963 mm | 971 mm | 977 mm | 993 mm | 1013 mm |
| Bottom Bracket Drop | 71 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 157 cm | 168 cm | 178 cm | 188 cm |
About this model
STRADA RIVAL XPLR 1X12 belongs to the 3t Strada model. 43 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the 3T STRADA FORCE D1 AXS 2X12 2023 has a starting price of 5074$. 3T Strada X Automobili Lamborghini 2023 on the other hand is the most expensive at 8999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 5199$. Comparing this to the average Aero bike price, we see that the price is 23.46% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the STRADA RIVAL XPLR 1X12 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. 3T STRADA RIVAL XPLR 1X12 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
