Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Strada TEAM
Suspension Fork
3T Fundi TEAM
Drivetrain
Rear Derailleur
Campagnolo EKAR 1x13
Shift Levers
Campagnolo EKAR 1x13
Cassette
Campagnolo EKAR 13-speed, 9-36T
Crank
Campagnolo EKAR carbon, 40T chainring (to match 9T smallest cog) (XS: 165mm - S: 170mm - M: 172,5mm - L: 175mm - XL: 175mm)
Wheels
Rims
Campagnolo Shamal Carbon, 700c, 21mm internal width, tubeless-ready (no tape required)
Brakes
Brakes
Campagnolo EKAR hydraulic disc w/ 160mm Campagnolo rotor
Cockpit
Stem
3T Apto Stealth (XS: 80mm - S: 90mm - M: 100mm - L: 110mm - XL: 120mm)
Headset
Sealed cartridge 1.125" - 1.25"
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.4 mm | 1.44 mm | 1.46 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 567 mm | 567 mm | 573 mm | 589 mm | 609 mm |
| Rake | 50 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 73 mm | 70 mm | 58 mm | 55 mm | 55 mm |
| Stack | 503 mm | 509 mm | 538 mm | 567 mm | 596 mm |
| Reach | 351 mm | 371 mm | 383 mm | 395 mm | 407 mm |
| Top Tube Length | 509 mm | 531 mm | 552 mm | 573 mm | 594 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 487 mm | 500 mm | 506 mm | 518 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 71.2 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 119 mm | 119 mm | 143 mm | 172 mm | 202 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 963 mm | 963 mm | 969 mm | 985 mm | 1006 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 157 cm | 168 cm | 178 cm | 188 cm |
About this model
Strada TEAM EKAR 1×13 is part of the 3t Strada model. 43 bikes variations carry this model name so far. Take a sneak peek at all 3t Strada bikes models from 2022, by clicking here.
Model range prices
The most economical model, the 3T Strada TEAM EKAR 1×13 2022 has a starting price of 4999$. 3T Strada Team Ekar Grey/Gold 2022 on the other hand is the most expensive at 4999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2022 and its price was 4999$. Comparing the average cost of an Aero bike to this one, you will see that Strada TEAM EKAR 1×13 price is 18.71% higher.
Strada TEAM EKAR 1×13 components
Fork material
Strada TEAM EKAR 1×13 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Strada TEAM EKAR 1×13 are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. 3T Strada TEAM EKAR 1×13 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
