Alchemy ARGOS – Shimano XTR 2023
2023 Mountain
Estimate price |
7,499$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 29" -
Travel Front 140mm -
Fork Fox Factory Float 34
-
Groupset Dura-Ace -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
165cm - 177cm
LG
175cm - 188cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Handmade in Colorado // USA Made Titanium // Custom Paint & Geometry Options.
Suspension Fork
Fox 34 29 Factory Kashima 140mm Boost 15mm Grip 2
Drivetrain
Rear Derailleur
Shimano XTR M-9100 12 Speed
Shift Levers
Shimano XTR M-9100 12 Speed
Cassette
Shimano XTR M-9101 10-51t
Crank
Shimano XTR M-9120-1 170mm 32t
Bottom Bracket
Shimano XTR BSA Threaded
Chain
Shimano XTR 12sp
Wheels
Rims
Front: Industry 9 1/1 TR-S Carbon, 6-Bolt 15x110, Rear: Industry 9 1/1 TR-S Carbon, 6-Bolt 12x148 HG
Tires
Maxxis Minion DHF/DHR 29x2.3
Brakes
Brakes
Shimano XTR M9120 4 Piston
Cockpit
Stem
TAG Metals T1 CNC Aluminum 35mm Clamp 45mm Length
Handlebar
Tag Metals T1 Carbon 35mm/800mm/20mm
Grips
DMR Deathgrip Thin
Headset
Cane Creek 40 Series IS42/5
Seat
Saddle
Selle Italia X-Base FeC Alloy
Seatpost
Fox Factory 175mm Transfer w/ Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.472 mm | 1.374 mm | 1.324 mm | 1.283 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 739 mm | 769 mm | 796 mm | 823 mm |
| Rake | 45 mm | 45 mm | 44 mm | 44 mm |
| Trail | 125 mm | 125 mm | 126 mm | 126 mm |
| Stack | 624 mm | 624 mm | 633 mm | 643 mm |
| Reach | 424 mm | 454 mm | 478 mm | 501 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1167 mm | 1197 mm | 1225 mm | 1252 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 791 mm | 803 mm | 820 mm | 844 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 165 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 177 cm | 188 cm | 195 cm |
About this model
ARGOS – Shimano XTR is part of the Alchemy Argos model. Alchemy launched 18 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Alchemy ARGOS – SRAM GX Eagle 2023 is the most economical model, with a starting price of 6299$. Alchemy ARGOS Au – sram XX1 AXS 2023 on the other hand costs 8999$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Alchemy released this model in 2023, its price was 7499$. If we compare this with the average Trail bike cost we notice that the price is 171.51% higher.
ARGOS – Shimano XTR components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the ARGOS – Shimano XTR model has 29″ carbon wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ARGOS – Shimano XTR comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 195 cm (5.18 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Alchemy ARGOS – Shimano XTR includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
