Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 29" -
Travel Front 120mm -
Fork Fox Factory Float 34
-
Groupset XTR -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
165cm - 177cm
LG
175cm - 188cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox 34 Factory Kashima 120mm Boost 15mm Grip 2
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XTR M9120, XTR SGS, 12-SPEED
Shift Levers
Shimano XTR M9100 12 Speed
Cassette
Shimano XTR M9100 12-Speed 11-51t
Crank
Shimano XTR FC-M9100-1 32 T 175mm
Bottom Bracket
Shimano XTR Threaded
Chain
Shimano XTR 12 Speed
Wheels
Rims
ENVE M525 I9 Hub 15/110mm
Tires
Maxxis Minion DHF 29×2.3 3c EXO TR, Maxxis Ardent Race 29×2.3 3c EXO TR
Brakes
Brakes
Shimano XTR M9120 Trail Hydraulic
Disk Rotors
Shimano XTR M900 180mm Center Lock Ice Tech Rotor
Cockpit
Stem
ENVE M6 55mm 31.8mm
Handlebar
ENVE M6 780mm 7.5 Degree 31.8mm
Grips
Ergon GA 20 Black
Seat
Saddle
WTB Volt Race 142X165
Seatpost
Fox Transfer Factory w Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 681 mm | 710 mm | 739 mm | 772 mm |
| Rake | 48 mm | 48 mm | 49 mm | 48 mm |
| Trail | 100 mm | 100 mm | 98 mm | 100 mm |
| Stack | 611 mm | 621 mm | 630 mm | 639 mm |
| Reach | 409 mm | 434 mm | 459 mm | 489 mm |
| Top Tube Length | 599 mm | 624 mm | 644 mm | 684 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1109 mm | 1138 mm | 1167 mm | 1200 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 165 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 177 cm | 188 cm | 195 cm |
Model Overview
Ark Ti — XTR completes the Alchemy Ark model. Alchemy launched 4 bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Alchemy Ark Ti — X01 Eagle 2019 is the cheapest bike model and costs 6799$. Alchemy Ark Ti — XTR 2019 is the most expensive one and costs 8399$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 8399$. Doing a quick comparison, we notice that Ark Ti — XTR price is 204.09% more expensive than the average cost of a Trail bike.
Ark Ti — XTR components
Fork
The Ark Ti — XTR comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Ark Ti — XTR 2019 bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Alchemy Ark Ti — XTR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Alchemy Ark Ti — XTR bike has 4 sizes, in the range of 158 cm – 195 cm (5.18 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
