Alchemy ATLAS CARBON – Shimano Dura Di2 2022
2022 Road
Estimate price |
10,499$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
160cm - 167cm
54cm
164cm - 174cm
56cm
171cm - 182cm
58cm
179cm - 189cm
61cm
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Handmade in Colorado // Alchemy Premium Carbon // Custom Paint & Geometry Options.
Drivetrain
Rear Derailleur
Dura Ace RD-R9250 Di2
Front Derailleur
Dura Ace FD-R9250 Di2
Shift Levers
Dura Ace ST-R9270 Di2
Cassette
Dura Ace CS-R9200 11-34t
Crank
Dura Ace FC-R9200 50/34t 170mm/172.5mm
Bottom Bracket
Shimano SM-BBR9200 BSA
Chain
Shimano CN-M9200
Wheels
Rims
Alchemy Carbon Road / All-Road
Tires
Teravail Rampart 28c/38c
Brakes
Brakes
Dura Ace BR-R9270 Hydraulic
Cockpit
Stem
Alchemy Carbon 100mm/110mm
Handlebar
Alchemy Carbon 42cm/44cm
Headset
Cane Creek 40 Series
Seat
Saddle
Fizik Antares R7
Seatpost
Alchemy Carbon 27.2mm 0mm/25mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.44 mm | 1.47 mm | 1.5 mm | 1.49 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 580 mm | 590 mm | 600 mm | 620 mm |
| Rake | 42 mm | 44 mm | 43 mm | 44 mm | 43 mm |
| Trail | 60.8 mm | 58.6 mm | 57.4 mm | 55.5 mm | 53.7 mm |
| Stack | 527 mm | 550 mm | 570 mm | 590 mm | 610 mm |
| Reach | 368 mm | 381 mm | 388 mm | 394 mm | 409 mm |
| Seat Tube Angle | 74 ° | 73.8 ° | 73.5 ° | 73.2 ° | 72.8 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 575 mm |
| Head Tube Angle | 71.5 ° | 73 ° | 73.2 ° | 73.5 ° | 73.8 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 970 mm | 978 mm | 988 mm | 998 mm | 1015 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 748 mm | 768 mm | 788 mm | 813 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 189 cm | 193 cm |
About this model
ATLAS CARBON – Shimano Dura Di2 belongs to the Alchemy Atlas model. There are 59 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Alchemy Atlas Titanium – 28mm 2022 has a starting price of 8999$. Alchemy ATLAS CARBON Au – Shimano Dura Ace Premium 2022 on the other hand is the most expensive at 11499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Alchemy ATLAS CARBON – Shimano Dura Di2 price was 10499$. In conclusion, this bike price is 213.4% higher than the price of the average Race bike.
ATLAS CARBON – Shimano Dura Di2 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the ATLAS CARBON – Shimano Dura Di2 bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Alchemy ATLAS CARBON – Shimano Dura Di2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Alchemy ATLAS CARBON – Shimano Dura Di2 bike has 5 sizes, in the range of 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
