Alchemy ATLAS CARBON – SRAM Force AXS 2022
2022 Road
Estimate price |
8,999$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
160cm - 167cm
54cm
164cm - 174cm
56cm
171cm - 182cm
58cm
179cm - 189cm
61cm
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Handmade in Colorado // Alchemy Premium Carbon // Custom Paint & Geometry Options.
Drivetrain
Rear Derailleur
SRAM Force eTap AXS
Front Derailleur
SRAM Force eTap AXS
Shift Levers
SRAM Force eTap AXS HRD
Cassette
SRAM Force XG-1270 10-33t
Crank
SRAM Force DUB 48/35t 170mm/172.5mm
Bottom Bracket
SRAM DUB PF86.5
Chain
SRAM Force Flattop Chain
Wheels
Rims
Alchemy Carbon Road / All-Road
Tires
Teravail Rampart 28c/38c
Brakes
Brakes
SRAM Force HRD Flat Mount
Cockpit
Stem
Alchemy Carbon 100mm/110mm
Handlebar
Alchemy Carbon 42cm/44cm
Headset
Cane Creek 40 Series
Seat
Saddle
Fizik Antares R7
Seatpost
Alchemy Carbon 27.2mm 0mm/25mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.44 mm | 1.47 mm | 1.5 mm | 1.49 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 580 mm | 580 mm | 590 mm | 600 mm | 620 mm |
| Rake | 42 mm | 44 mm | 43 mm | 44 mm | 43 mm |
| Trail | 60.8 mm | 58.6 mm | 57.4 mm | 55.5 mm | 53.7 mm |
| Stack | 527 mm | 550 mm | 570 mm | 590 mm | 610 mm |
| Reach | 368 mm | 381 mm | 388 mm | 394 mm | 409 mm |
| Seat Tube Angle | 74 ° | 73.8 ° | 73.5 ° | 73.2 ° | 72.8 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 575 mm |
| Head Tube Angle | 71.5 ° | 73 ° | 73.2 ° | 73.5 ° | 73.8 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 970 mm | 978 mm | 988 mm | 998 mm | 1015 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 748 mm | 768 mm | 788 mm | 813 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 164 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 189 cm | 193 cm |
Model Overview
ATLAS CARBON – SRAM Force AXS completes the Alchemy Atlas model. 59 bikes variations carry this model name so far. Take a sneak peek at all Alchemy Atlas bikes models from 2022, by clicking here.
Model range prices
Alchemy Atlas Carbon – 38mm 2022 is the most economical model, with a starting price of 8999$. Alchemy ATLAS CARBON Au – Shimano Dura Ace Premium 2022 on the other hand costs 11499$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Alchemy ATLAS CARBON – SRAM Force AXS price was 8999$. If we compare this with the average Race bike cost we notice that the price is 168.63% more expensive.
ATLAS CARBON – SRAM Force AXS components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The ATLAS CARBON – SRAM Force AXS 2022 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Alchemy ATLAS CARBON – SRAM Force AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 160 cm – 193 cm (5.25 ft – 6.33 ft). In short, you can easily find one that suits you.
