Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Sektor
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
612 Select CroMoly steel. Double butted down, top, and seat tubes. Externally tapered, ovalized, and dimpled chain stays, tapered seat stays, replaceable derailleur hanger. Stealth dropper post routing.
Suspension Fork
RockShox SEKTOR 120mm 29er Boost
Drivetrain
Rear Derailleur
SRAM NX-Eagle
Front Derailleur
N/A
Shift Levers
SRAM NX-Eagle
Cassette
SRAM PG1230 Eagle 11-50
Crank
SRAM NX-Eagle 32t, DUB, Boost
Bottom Bracket
SRAM DUB
Chain
SRAM NX-Eagle
Wheels
Front Hub
WTB Boost 110/148, 32h
Rear Hub
WTB Boost 110/148, 32h
Rims
WTB ST i40, 27.5, 32h
Tires
WTB Ranger 27.5 x 2.8", TCS
Brakes
Brakes
SRAM Level, 180mm/160mm Centerline Rotors
Cockpit
Stem
Promax 3D Forged Stem, 60mm
Handlebar
Salsa Rustler, 700mm/750mm/800mm
Grips
Locking Grip, Black
Headset
Cane Creek 40 Series
Seat
Saddle
All-City Gonzo
Seatpost
TranzX YSP12 Dropper, 100mm travel, underbar thumb lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.5 mm | 1.43 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 648 mm | 688 mm | 719 mm | 750 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 601.1 mm | 610.7 mm | 620.2 mm | 629.7 mm | 639.1 mm |
| Reach | 369.9 mm | 407.1 mm | 434.2 mm | 461.3 mm | 478.3 mm |
| Top Tube Length | 569.5 mm | 609.5 mm | 639.6 mm | 669.6 mm | 689.7 mm |
| Seat Tube Angle | 71.4 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 356 mm | 400 mm | 445 mm | 483 mm | 525 mm |
| Head Tube Angle | 67.6 ° | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1076 mm | 1117 mm | 1147 mm | 1178 mm | 1199 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 708 mm | 745 mm | 779 mm | 812 mm | 843 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Electric Queen belongs to the Allcity Queen model. There are 4 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When All City released this model in 2019, its price was 2399$. Comparing this to the average Trail bike price, we see that the price is 15.13% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The fork installed on this bike is the RockShox Sektor model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Electric Queen bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
All City Electric Queen comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
